IC-M605EURO fixed marine VHF

The Icom IC-M605EURO fixed marine VHF is an ASN Class D radio designed for demanding sailors. This flagship model stands out for its system flexibility and advanced performance, offering a complete maritime communication solution for all types of vessels. Priced at €1,100.22, it positions itself as a premium alternative to standard VHF radios, integrating features typically reserved for more complex systems.

Flexibility and Advanced Display

The IC-M605EURO provides maximum operational flexibility with the ability to connect up to three remote controllers: the RC-M600 control head and/or the HM-229B/W COMMANDMIC™ micro-controls. An intercom function is available between the main unit and controllers, enabling easy communication on board. Its 4.3-inch TFT LCD color screen offers a nearly 180-degree viewing angle, ensuring optimal readability of characters and icons. A night mode improves visibility in low light. The intuitive user interface, combining a directional pad and programmable keys, simplifies access to common functions, while the numeric keypad allows quick entry of channel or MMSI numbers.

Integrated Safety and Connectivity

For enhanced safety, the IC-M605EURO includes an AIS receiver displaying real-time traffic information. A combined AIS display allows monitoring of the AIS plotter during basic operations and initiating a direct ASN call to a selected AIS target. Unlike models such as the Icom IC-M330, which do not include AIS, or some competing VHF radios requiring an external AIS transponder, the direct integration of this function in the IC-M605EURO simplifies installation and use. A built-in GNSS receiver (GPS, GLONASS, and SBAS) is also included, with a 5-meter UX-241 GNSS antenna provided, ensuring precise positioning without additional equipment.

Audio Performance and Durability

The receiver performance of the IC-M605EURO is commercial-grade, with selectivity and intermodulation exceeding 75 dB, enabling clear reception of weak signals even near strong ones. Active noise suppression technology eliminates background noise during transmission and reception, ensuring clear communications. The voice recording function stores up to two minutes of the last call. The unit features a waterproof internal speaker with over 15 W audio power and an external 4 Ω speaker for powerful, clear sound. It is compatible with NMEA 2000™ and NMEA 0183/-HS standards for exchanging GNSS data, AIS, ASN calls, and frequency information. Its durability is confirmed by IPX8 waterproofing (1 meter for 50 minutes) and compliance with U.S. military MIL-STD-810G specifications (shock, vibration, humidity, extreme temperatures, etc.), placing it above standard VHF radios in terms of robustness.

Specific Features and Technical Specifications

The IC-M605EURO includes a 30 W bidirectional deck speaker and a four-pattern automatic foghorn function with optional SP-37 speaker. It supports dual and triple watch functions, AquaQuake™ drainage, and an instant access button for channel 16 and calls. The supplied HM-205RB high-speaker microphone can be connected to the rear panel. It is compatible with Icom’s MarineCommander™ marine navigation system and supports four-digit channels since January 1, 2017. The transmitter operates on a frequency range of 156.025–161.425 MHz (Tx) and 156.025–162.000 MHz (Rx), with an output power of 25 W or 1 W. Power requirement is 13.8 V DC (10.8–15.6 V DC), with a consumption of 6.0 A at 25 W transmission. Weight is 1,510 g.
