Marinco

M5100P9

100 A 120/208 V Menekes # M5100P9M plug

Name: 100 A 120/208 V Menekes # M5100P9M plug
Brand: Marinco
SKU: M5100P9
Price: 1070.0 EUR
Availability: InStock

The Marinco 100A 120/208V Plug Menekes (M5100P9) is a waterproof IP67 male connector for 100-ampere 3-phase Y shore power systems. cULus certified, it provides a secure and robust connection for high-power marine equipment.

Retail priceBenefit from the professional rate

1.070,00€

Shipping calculated at checkout.

Prices shown excluding VAT for Türkiye. If your delivery address is in the European Union, the VAT of the destination country will be added at checkout.

Available in stock

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

thanks to our network of approved installers

Find an installer

Support service

Opt for additional installation assistance

Technical specifications

Cable type	Power cable
Cross-section (mm²)	53.5
Wire gauge (AWG)	0.0
Number of conductors	5.0
Color	Yellow
Max voltage	208.0
Current type	AC
Outer diameter of cable (mm)	50.0
Conductor material	Brass
Certifications	cULus
Conductor finish	Nickel-plated
Connector Gender	Male
Connector type	Pin and sleeve
Contact Carrier Material	Nylon
Current rating	100
Housing material	Nylon/ABS blend
IP rating	IP67
Operating voltage	120/208
Phase Type	Three-phase Y
Pole Count	4
Product type	Power connector
Terminal type	Pillar

Detailed description

The Marinco 100A 120/208V Plug Menekes (M5100P9) is a watertight male plug connector with pin and sleeve design, intended for shore power applications. This plug is designed for marine electrical systems requiring a robust and secure three-phase Y connection capable of handling high currents.

Design and Materials

This plug features a housing made of a nylon and ABS blend in yellow, providing resistance to marine environments. The contact carrier is nylon. The contacts are solid brass with nickel plating, and the terminals are stud type with double brass nickel-plated terminal screws, accommodating cables from 1/0 to 3 AWG. The connector can accommodate an outer cable diameter of 0.98" to 1.97".

Electrical Performance and Safety

The Marinco M5100P9 is rated for 100 amperes and 120/208 volts in a three-phase Y configuration. It uses 4-pole, 5-wire wiring. Its overall design ensures watertightness compliant with IP67 per IEC 60529, providing protection against temporary immersion. It is certified by Underwriters Laboratories, Inc. (cULus) for the United States and Canada, with file E106703, attesting to its compliance with safety standards.

Documentation

Type	Nom
	Fiche technique - 100A 120/208V PLUG MENEKES # M

Payment and security

Your payment information and data are processed securely.

100 A 120/208 V Menekes # M5100P9M plug

1.070,00€

Frequently Asked Questions

Need help? Contact us

What type is this Marinco M5100P9 connector?

The Marinco M5100P9 is a waterproof male connector of the pin & sleeve type, designed for marine electrical connections.

What are the electrical specifications of this Marinco socket?

This socket is rated for 100 amperes and 120/208 volts. It is designed for 3-phase Y electrical systems.

What materials is the M5100P9 socket housing made of?

The M5100P9 plug housing is made from a blend of nylon and ABS, providing good resistance for marine environments.

What is the pinout and wire configuration of this connector?

This connector is configured for 4-pole and 5-wire wiring, suitable for 3-phase Y systems.

What is the waterproof rating of the Marinco M5100P9 plug?

The Marinco M5100P9 socket has an IP67 ingress protection rating, in accordance with IEC 60529 standard. This means it is protected against temporary immersion.

What safety certifications does this Marinco product have?

This product is certified by Underwriters Laboratories, Inc. (cULus) for the United States and Canada, under file E106703, ensuring compliance with applicable safety standards.

What is the color of the Marinco 100A plug?

The Marinco connector housing for this unit is yellow.

Which type of application is this connector primarily designed for?

This socket is primarily designed for shore power applications in marine electrical systems, requiring a robust and secure connection.

What is the material of the contacts in this connector?

The contacts on this connector are made of solid nickel-plated brass, ensuring good conductivity and corrosion resistance.

What type of electrical connection sockets are used?

The terminals are pillar-type and feature double nickel-plated brass terminal screws for secure cable connections.

What is the material of the contact mount?

The contact carrier of this connector is made of nylon.

Is this connector a male or female connector?

This is a male connector.

Which cable gauges (AWG) are compatible with the terminals of this connector?

The terminals on this socket can accommodate cables from 1/0 to 3 AWG gauge.

What is the minimum and maximum outer diameter of the cable that this connector can accommodate?

This socket is designed to accommodate cables with an outer diameter (OD) ranging from 0.98 inch (approximately 2.49 cm) to 1.97 inch (approximately 5.00 cm).

How are the cables secured to the terminal block?

Wires are secured to pillar-type terminals using nickel-plated brass double terminal screws, ensuring a solid and reliable connection.

Is this socket suitable for single-phase electrical systems?

No, this socket is specifically designed for three-phase Y electrical systems and is not suitable for single-phase systems.

Is it compatible with 120V shore power systems only?

No, it is designed for 120/208 V shore-power systems in 3-phase Y configuration, not for 120 V single-phase systems.

Can the Marinco M5100P9 connector be used with cables from different brands?

Yes, the connector can be used with cables from different brands, provided these cables meet the required gauge specifications (1/0 – 3 AWG) and outer diameter (0.98" – 1.97") for this connector.

Is this Marinco connector compliant with international waterproofing standards?

Yes, the Marinco M5100P9 connector complies with the international IP67 ingress protection rating per IEC 60529.

What are the specific safety standards for the United States and Canada to which this product is compliant?

This product is listed by Underwriters Laboratories, Inc. (cULus) for the United States and Canada, under file E106703, certifying its compliance with safety standards in force in these regions.
