RELiON

BI-3140R-2448

BATT INDIC INSIGHT GC2 3140R2448

The RELiON BI-3140R-2448 InSight GC2 battery monitor provides precise state-of-charge (SOC) monitoring for Relion InSight GC2 LiFePO₄ lithium batteries (24V and 48V). It communicates via CANbus, displaying real-time SOC for up to 14 batteries in parallel with "LOBATT" alerts and IP67 protection.

Delivered as a single unit, no accessories included.

Retail priceBenefit from the professional rate

187,24€

Shipping calculated at checkout.

In stock

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

thanks to our network of approved installers

Find an installer

Support service

Opt for additional installation assistance

Technical specifications

Battery technology	Lithium Iron Phosphate (LiFePO₄)
Wired network	CAN
Max batteries in series	0.0
Max batteries in parallel	14
Terminal size	Proprietary cable harness
Storage temperature range	10 to 35 °C
IP rating	IP67
Weight	0.2
Available alarms	Low battery (LOBATT <20% SOC, flashing <10% SOC)
Nombre de parcs de batteries	1
Integrated battery monitoring	Oui
Protocole de communication	CANbus
Séries de batteries compatibles	RELiON InSight GC2
Critical Low Soc Alarm Threshold	10
Compatible CZone	No
Display Backlight	Yes
Display type	Backlit LCD
Installation type	Plug-and-play
Low Soc Alarm Threshold	20
Compatible MasterBus	No
Max Monitored Batteries	14
Plage de tension mesurée	24-48 V
Monitored Parameters	State of charge (SOC),Number of batteries
Operating voltage range	24-48 V
Power On Method	Long press (5s) on the button
Power source	Battery for the system
Product Type Category	Battery indicator
Surveillance batterie de service	Complete (SOC, voltage, current)
Shunt inclus	No
Soc Display Range	0-100
Surveillance batterie de démarrage	No

Detailed description

The RELiON BI-3140R-2448 InSight GC2 battery monitor is designed for precise state-of-charge (SOC) tracking of RELiON InSight GC2 series lithium LiFePO₄ batteries. This accessory is compatible with 24V and 48V battery systems, providing an integrated monitoring solution.

Accurate state-of-charge monitoring

This monitor operates by receiving real-time current data from all InSight batteries connected in parallel via the CANbus protocol. It then calculates the state of charge (SOC) in remaining ampere-hours, displayed as a percentage from 0 to 100 %. The system can monitor up to 14 InSight batteries connected in parallel, ensuring centralized management of the entire battery bank.

Display and features

The backlit display of the monitor ensures constant visibility. It shows the SOC percentage and the number of detected batteries. Specific alert messages are integrated: an "LOBATT" message appears when the battery bank drops below 20 % SOC, and this message flashes when SOC is below 10 %. Installation is designed to be simple and direct, presented as a "plug-and-play" accessory.

Technical and environmental specifications

The RELiON BI-3140R-2448 has an operating current of 29 mA. It is designed to operate within a temperature range of -10°C to 85°C (14°F to 185°F) and can be stored from -40°C to 85°C (-40°F to 185°F). Its IP67 rating ensures high protection against dust and temporary immersion in water. The housing is made of ABS with a UL94 V-0 flammability rating, and the product weighs 0.2 kg.

Documentation

Type	Nom
	EN - Manuel utilisateur InSight avec section indicateur 24/48 V

Expert opinion

Pol CONIN

Digital Manager

« Energy management with the Relion InSight GC2 indicator »

The RELiON BI-3140R-2448 battery indicator is a critical component for any installation using RELiON InSight GC2 series LiFePO₄ batteries. Its value lies in its ability to provide accurate, real-time readings of the state of charge (SOC) across the entire battery bank—a crucial data point for optimizing range and preventing deep discharges, which can damage lithium batteries.

This "fuel gauge" stands out from simple voltmeters by its direct integration with the battery management system (BMS) of InSight batteries via CANbus. This native communication ensures superior data accuracy, as it accounts for charge and discharge history—not just instantaneous voltage. For multi-battery installations, the indicator can consolidate data from up to 14 batteries connected in parallel, providing a unified overview. Its installation is simplified by a "plug-and-play" design, easing integration into existing systems. It is important to note that this indicator is specifically designed for RELiON InSight GC2 batteries and will not be compatible with other brands or battery types.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

BATT INDIC INSIGHT GC2 3140R2448

187,24€

Frequently Asked Questions

Need help? Contact us

What is the RELiON BI-3140R-2448 InSight GC2 battery indicator?

The RELiON BI-3140R-2448 InSight GC2 battery monitor is an accessory designed for precise state-of-charge (SOC) tracking of RELiON InSight GC2 series LiFePO₄ lithium batteries. It provides an integrated monitoring solution for 24V and 48V battery systems.

What information does the battery indicator display?

The indicator displays the state of charge percentage (SOC) of the batteries, ranging from 0 to 100%, as well as the number of InSight batteries detected and connected in the system.

How does the battery monitor calculate the state of charge (SOC)?

It operates by receiving real-time current data from all InSight batteries connected in parallel via the CANbus protocol. It then calculates the remaining state of charge in ampere-hours, which is displayed as a percentage.

What types of alerts can the RELiON battery monitor display?

The indicator includes specific alert messages. An "LOBATT" message appears when the battery bank drops below 20 % SOC. This message flashes when SOC is below 10 %.

Is the display of the indicator visible in all conditions?

Yes, the display is equipped with a backlit screen to ensure constant visibility of the displayed information, even in low-light conditions.

Which battery technology is supported by this indicator?

This indicator is specifically designed for lithium LiFePO₄ (Lithium Iron Phosphate) batteries from the InSight GC2 series by RELiON.

What is the weight of this battery monitor?

The RELiON BI-3140R-2448 InSight GC2 battery monitor weighs 0.2 kg.

With which batteries is the RELiON BI-3140R-2448 indicator compatible?

This indicator is compatible only with LiFePO₄ lithium batteries from the RELiON InSight GC2 series.

Which system voltages are supported by this display?

The RELiON BI-3140R-2448 battery monitor is compatible with 24V and 48V battery systems.

Is this indicator compatible with RELiON InSight 12V batteries?

No, the BI-3140R-2448 indicator is specifically designed for 24V and 48V systems. For 12V InSight batteries, a different indicator model (BI-3140R-12) is required.

Can I use this indicator with lithium batteries from other brands?

No, this indicator is specifically designed to work with RELiON InSight series batteries and uses their exclusive CANbus communication protocol for accurate monitoring.

What communication protocol does the display use?

The indicator uses the CANbus protocol to communicate with InSight batteries, enabling it to receive real-time current data and calculate the state of charge.

Is the battery monitor installation complicated?

No, the installation of the display is designed to be simple and straightforward, presented as a "plug-and-play" accessory for quick commissioning.

How does the indicator receive battery data?

The display receives real-time current data from all InSight batteries connected in parallel via the CANbus protocol, enabling precise state-of-charge calculations.

Is it necessary to configure the display after installation?

The indicator is designed to be a "plug-and-play" accessory, meaning it requires minimal or automatic configuration once properly connected to the InSight batteries.

Is the cable harness for connecting the display included?

No, the cable harness required to connect the gauge (such as the "Wire BI-3140-03 InSight Fuel Gauge Wire Harness") is an accessory sold separately and is not included with the gauge alone.

Where is this battery monitor manufactured?

The country of manufacture for this battery monitor is China (CN).

Is this indicator suitable for marine use?

Although the description does not explicitly mention "marine", RELiON InSight batteries are commonly used in nautical applications. This indicator is therefore suitable for monitoring these batteries in various environments, including marine ones, where 24V or 48V systems are in place.

How does the indicator manage multi-battery systems?

The indicator is designed to effectively monitor multi-battery systems by receiving real-time current data from all InSight batteries connected in parallel via the CANbus protocol. It can manage up to 14 batteries for centralized state-of-charge calculation.
