Garmin

010-13307-00

Pedals with mounting rails for Garmin Force Current

These wireless foot pedals control the Garmin Force Current electric motor. They provide hands-free foot steering, ideal for kayak fishing, with programmable functions such as heading hold and anchor lock. The system is robust and water-resistant to IPX7 standards.

Supplied as a single unit with mounting rails, batteries not included.

Price excl. import taxesBenefit from the professional rate

£452.63 GBP

£452.63 GBP ~~£511.55 GBP~~

Shipping calculated at checkout.

Prices exclude import taxes. DAP delivery: import taxes are paid on delivery.

Available in stock

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

thanks to our network of approved installers

Find an installer

Support service

Opt for additional installation assistance

Technical specifications

Fishing type	Sea, Lake, River, Kayak / float tube
Autopilot Control	Yes
Battery type	2 × AA batteries per pedal (not included)
Compass safe distance	61
Compatible model	Garmin Force Current electric motor (010-02864-00 and 010-02864-10)
Compatible models	Garmin Force Current
Controlled Functions	Direction, speed forward and reverse, course hold (left lever), Anchor Lock (right lever); programmable levers: Anchor Lock, course hold, mark a waypoint
Gps Features Access	Yes
Ingress protection	IPX7
Operating temperature range	-5 to 40 °C
Package contents	Two Power Steer pedals (left and right) with mounting rails; AA batteries not included
Product type	Power Steer wireless control pedals
Storage temperature range	-40 to 85 °C
Weight	3.08
Wireless frequency	2.4

Detailed description

Designed for Garmin Force Current electric motors, these pedals with mounting rails 010-13307-00 provide precise wireless foot control. The system allows users to navigate and maneuver their kayak with smooth operation, freeing up hands for other essential tasks such as fishing.

Features and control

This pedal system comes with levers preconfigured for key functions: the left lever activates Heading Hold and the right lever manages Anchor Lock. Users can also program these levers to include waypoint marking, offering increased flexibility for various navigation and fishing situations. Wireless connectivity ensures simplified installation and responsive operation.

Robust design and technical specifications

The Garmin 010-13307-00 pedals are designed to withstand marine environments, featuring IPX7 water resistance per IEC 60529 standards. The total weight of the complete system, including rails, is 3.08 kg. They operate within a temperature range of -5°C to 40°C and can be stored from -40°C to 85°C. The safe distance from a compass is 61 cm. Each pedal is powered by two AA batteries (not included). The wireless frequency is 2.4 GHz with a maximum transmission power of 9.1 dBm.

Expert opinion

« Wireless foot control for Force Current engine »

These Garmin pedals are a strategic addition for any user of the Force Current electric motor, particularly those fishing from kayaks or requiring precise, hands-free control. Wireless integration with the Force Current motor simplifies installation by avoiding additional cable runs on deck, a notable advantage for kayaks where space is limited and clean installation is critical.

Their practical value is clear during drift-fishing sessions or when holding position. The ability to program lever functions beyond default settings (course-keeping and anchor lock) offers useful customization to tailor the interface to specific outings, such as quick waypoint marking. Powered by AA batteries, their battery life is managed independently of the kayak’s main electrical system, which can be an asset for redundancy and maintenance simplicity.

Choosing this pedal system means opting for optimized piloting ergonomics, allowing maximum focus on the primary activity—whether casting, fighting a fish, or monitoring the fishfinder.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Pedals with mounting rails for Garmin Force Current

£452.63 GBP

£452.63 GBP ~~£511.55 GBP~~

Frequently Asked Questions

Need help? Contact us

Are these pedals compatible with other Garmin trolling motor models?

No, these pedal units with mounting rails are only compatible with the Garmin Force Current trolling motor. They are designed to be paired individually with this specific motor.

How do the pedals connect to the motor and how are they powered?

These pedals connect to the Garmin Force Current trolling motor via a 2.4 GHz wireless link. Each pedal is paired separately with the motor for precise control.

Each pedal requires two AA batteries for power; these are not included with the product.

How do the pedals allow control of the engine’s direction and speed, and what actions can be assigned to their levers?

Direction and speed control (forward and reverse) of the trolling motor is operated by tilting the two pedals.

By default, the left pedal lever activates or deactivates the Heading Hold function. The right pedal lever activates or deactivates the Anchor Lock GPS function.

Each lever can be reprogrammed to activate one of the following functions: Anchor Lock GPS, Heading Hold, or waypoint marking.

Are the mounting rails included with the pedals?

Yes, the product includes the pedals with their mounting rails, ready for installation.

What type of batteries are recommended for the Garmin Force Current pedals, and are they included?

Each pedal requires two AA batteries to operate, for a total of four batteries for the complete system. Batteries are not included with the pedals.

Garmin recommends using lithium batteries for optimal performance and advises against using rechargeable batteries.

What is the weight of the complete system, including the pedals and mounting rails?

The weight of the complete system, including the pedals and mounting rails, is 3.08 kg.

Which specific navigation functions can the pedal lever controls activate?

The pedal levers allow you to activate the heading hold (Heading Hold) and GPS anchor lock (Anchor Lock) functions of the engine. They can also be programmed to mark a waypoint. A GPS signal is required by the engine for these functions to operate.

What is the waterproof rating of the Garmin Force Current pedals?

The Garmin Force Current pedals with mounting rails (part number 010-13307-00) have an IEC 60529 IPX7 waterproof rating.

How to physically install the pedals and mounting rails on my boat?

Physically installing the pedals and mounting rails on your boat involves several steps:

The mounting rails must be firmly screwed to the surface of your kayak. Each pedal is then attached to the corresponding rail carriage using a screw and a knurled nut. After physical installation, each pedal must be paired with the Force Current trolling motor. If the pedals are delivered with the motor, pairing is typically done at the factory.

What is the country of origin of this product?

These pedals with mounting rails are manufactured in Taiwan.

What are the recommended environmental conditions for using and storing these pedals?

To ensure optimal operation and extend the service life of your Garmin Force Current pedals, it is important to meet the following environmental conditions:

Operating temperature must be maintained between -5 °C and 40 °C. For storage, the recommended temperature range is -40 °C to 85 °C. It is also advisable to maintain a safe distance of 61 cm from a compass to avoid any interference.
