Access point for VHF Ray 90/91 when using a wireless handset A80544

The Raymarine A80540 wireless access point is a key component designed for Raymarine Ray90 and Ray91 modular VHF systems. Its primary role is to act as a central hub for wireless connectivity, enabling the integration of wireless handsets, such as the A80544 model, and wireless speakers. It thereby extends the communication capabilities onboard, providing users with increased flexibility.

The main advantages of the A80540 access point include:

Increased mobility: It allows the use of wireless handsets from any point on the vessel, without being tied to the main station.Flexible communication: It turns Ray90/91 VHF radios into versatile communication platforms.Discreet installation: Its compact dimensions make it easy to integrate on board.Stable performance: It ensures reliable connectivity for voice communications and DSC calls with wireless handsets.

No, the Raymarine A80540 access point is not a complete VHF system. It is an essential accessory that extends the functionality of Raymarine Ray90 and Ray91 modular VHF systems by adding wireless capability. It must be connected to a Ray90 or Ray91 base unit to operate.

The A80540 access point does not improve the transmission or reception range of the VHF itself. It extends the coverage area for the use of wireless handsets and speakers aboard the vessel, allowing users to communicate more freely at a distance from the VHF's main unit.

Raymarine products are designed for marine environments. While the document does not specify an exact IP rating for the A80540, it is built to be installed aboard a vessel. It is recommended to refer to the installation manual for specific guidelines regarding its placement to optimize durability and performance.

The Raymarine A80540 access point has compact dimensions. Its mounting base measures approximately 121.6 mm by 60.8 mm, and its height is approximately 79.9 mm. These dimensions are designed for discreet installation aboard.

The Raymarine A80540 access point is compatible with the Raymarine A80544 wireless handset (Raymic Wireless Handset). This handset is designed to integrate seamlessly with the system via the wireless hub.

No, the Raymarine A80540 access point is designed exclusively for wireless connectivity. It does not support the connection of wired handsets. Wired handsets connect directly to the Ray90 or Ray91 VHF base unit.

No, the Raymarine A80540 access point is a proprietary Raymarine accessory designed to work exclusively with Raymarine Ray90 and Ray91 modular VHF systems. It is not compatible with VHFs from other brands.

Yes, to ensure optimal compatibility and proper operation of the A80540 wireless hub, it is recommended to verify that the base unit of your Ray90 or Ray91 VHF is updated to the latest available software version to guarantee compatibility and optimal operation with the A80540 hub.

The Raymarine A80540 access point connects to the Ray90 or Ray91 VHF base unit via a dedicated cable. This connection powers the hub and enables communication with the VHF system to manage wireless handsets and speakers.

No, the Raymarine A80540 access point is typically powered directly by the base unit of the Ray90 or Ray91 VHF to which it is connected. It does not require a separate 12V power connection to the boat's electrical system.

Installation of the A80540 access point can be performed by a user with basic technical skills. However, Raymarine recommends installation by a Raymarine-certified installer. Certified installation may provide additional warranty benefits for the product.

Using an antenna extension accessory with the A80540 access point is optional. It can be considered to optimize wireless coverage and the range of wireless handsets, particularly on large vessels or in environments where wireless reception could be affected by obstructions.

Yes, for optimal wireless performance, it is important to consider the orientation of the A80540 hub antenna. The antenna must be positioned vertically and away from metal obstructions or other electronic equipment that could cause interference.

The A80540 wireless hub is designed for discreet installation. It must be mounted on a flat and stable surface, considering the compact dimensions of its base (121.6 mm by 60.8 mm). Ensure there is adequate space for cable routing and proper ventilation if required.

To optimize wireless coverage, install the A80540 access point in a central and elevated location on the boat, away from large metal surfaces, engines, or other sources of electromagnetic interference. Ensure the antenna is properly oriented and consider using an antenna extension accessory if the range is insufficient.
