Victron Energy

ORI241236120

Convertor/Încărcător Orion-Tr Smart 24/12-30A (360W) DC-DC izolat

Le VICTRON ENERGY Orion-Tr Smart 24/12-30A (360W) Isolated DC-DC est un convertisseur/chargeur 24V vers 12V offrant 30A de courant continu et une puissance de 360W. Sa conception isolée garantit une séparation galvanique, essentielle pour prévenir les boucles de masse et les interférences dans les systèmes électriques marins ou embarqués. Il intègre un algorithme de charge adaptatif à 3 étapes et une compatibilité avec les alternateurs intelligents, le tout configurable via Bluetooth Smart. L'unité est livrée avec ses bornes à vis pour une installation simplifiée.

Prix publicBénéficier du tarif pro

223,20€

223,20€ ~~313,20€~~

TTC Expediere calculată la momentul plății.

Stoc epuizat

Point relais offert dès 150€ en France
Retrait chez Skysat possible

Installation sur mesure

Faites confiance à Skysat pour installer l'équipement à bord

Demander un devis

Installateurs autour de vous

grâce à notre réseau d'installateurs agréés

Trouvez un installateur

Service d'assistance

Optez pour une aide complémentaire à la pose

Caractéristiques techniques

Absorption Time Default	2
Adaptive Absorption Time	Oui
Număr presetări baterie	8
Algoritm de încărcare	Adaptatif à 3 étapes (Bulk, Absorption, Float)
Detectare funcționare motor	Oui
Curent maxim de ieșire (10s)	45
Zgomot tensiune ieșire	2
Tensiune de repornire în caz de tensiune scăzută	15
Tensiune de oprire în caz de tensiune scăzută	14
Conectivitate wireless	Bluetooth

Description détaillée

Proiectat pentru sistemele de bord care necesită conversie izolată de tensiune, convertorul/încărcătorul VICTRON ENERGY Orion-Tr Smart 24/12-30A (360W) DC-DC izolat este o soluție pentru instalațiile de 24V care alimentează echipamente de 12V sau încarcă o baterie de serviciu de 12V. Acest model se remarcă prin izolația galvanică (200 VCC între intrare, ieșire și carcasă), esențială pentru prevenirea buclelor de masă și asigurarea siguranței electrice în medii marine complexe, în special pe ambarcațiuni cu carenă metalică sau vehicule cu cerințe specifice de masă. Oferă o putere continuă de 360W la 40°C, cu un curent de ieșire de 30A.

Funcționalități avansate și integrare

Orion-Tr Smart 24/12-30A integrează un algoritm de încărcare adaptativ în 3 etape (bulk, absorbție, float) care optimizează durata de viață a bateriilor cu plumb și litiu. Durata de absorbție este ajustată automat pentru bateriile cu plumb după o descărcare parțială, în timp ce pentru bateriile cu litiu este fixă (2 ore implicit). Această flexibilitate de încărcare este configurabilă prin aplicația VictronConnect, accesibilă prin Bluetooth Smart. Spre deosebire de modelele neizolate din gama Orion-Tr Smart, această variantă garantează o separare electrică completă între circuitele de intrare și ieșire, oferind o protecție sporită împotriva interferențelor și problemelor de masă.

Performanță și compatibilitate

Cu o plajă de tensiune de intrare de 20-35V și o tensiune de ieșire nominală de 12,2V (reglabilă între 10-15V), acest dispozitiv asigură o alimentare stabilă și fiabilă. Este compatibil cu alternatoarele inteligente (Euro 5 și Euro 6) printr-un mecanism de detectare a motorului în funcțiune, prevenind astfel descărcarea bateriei de pornire când alternatorul nu furnizează putere. Această funcționalitate simplifică instalarea prin eliminarea necesității de senzori externi. Randamentul este de 88%, iar dispozitivul este protejat împotriva scurtcircuitelor, suprasarcinilor și temperaturilor ridicate, cu reducere automată a puterii dacă este necesar. Instalarea este facilitată de borne cu șuruburi care acceptă cabluri până la 16 mm², iar mai multe unități pot fi conectate în paralel pentru a crește curentul de ieșire.

Avis de l'expert

Pol CONIN

Responsabil digital

« Technical analysis of the Orion-Tr Smart isolated DC-DC converter/charger 24/12-30A »

The Victron Energy Orion-Tr Smart 24/12-30A (360W) Isolated DC-DC converter/charger is a critical component for complex marine or onboard electrical architectures. Its 'isolated' feature is decisive: it ensures galvanic separation between the input circuit (often the 24V starter battery or a 24V alternator) and the output circuit (12V service battery or 12V equipment). This isolation is crucial to prevent ground loops, potential sources of electrolytic corrosion on metal hulls or electromagnetic interference in sensitive systems.

This model is particularly suited to installations where the grounds of the starter and service batteries must remain separate, or when the system requires enhanced protection against overvoltages and interference. Its ability to operate as a 3-stage adaptive charger, combined with intelligent engine-running detection, makes it a standalone and efficient solution for maintaining the charge of a 12V service battery from a 24V network without draining the starter battery. Bluetooth Smart integration via VictronConnect simplifies setup and monitoring, enabling parameter adjustments (charge voltages, fixed power mode) without specific tools or complex interfaces. For 24V systems needing to power or charge 12V equipment with rigorous electrical isolation, this Orion-Tr Smart is a technically relevant choice.

Durabilité

Facilité d'installation

Rapport performance / prix

Paiement et sécurité

Vos informations de paiement et données sont traitées de manière sécurisée.

Convertor/Încărcător Orion-Tr Smart 24/12-30A (360W) DC-DC izolat

223,20€

223,20€ ~~313,20€~~

Questions fréquentes

Besoin d'aide ? Contactez-nous

What is the Victron Energy Orion-Tr Smart 24/12-30A converter/charger used for?

This isolated DC-DC converter/charger is designed for onboard systems requiring voltage conversion. It can power 12V equipment or charge a 12V service battery from a 24V source. Its galvanic isolation provides complete electrical separation between input and output circuits, preventing ground loops and enhancing electrical safety, especially on metal-hulled boats or vehicles with specific grounding requirements.

What is the continuous output power of this device?

The Victron Energy Orion-Tr Smart 24/12-30A converter/charger delivers a continuous output power of 360W at an ambient temperature of 40°C.

What are the input and output voltages of this inverter/charger?

The input voltage range is 20 to 35V. The nominal output voltage is 12.2V, adjustable within a range of 10 to 15V.

What is the maximum output current that the Orion-Tr Smart 24/12-30A can supply?

The DC output current of this device is 30A at nominal output voltage and 40°C. The maximum output current (for 10 seconds) is 45A.

How important is galvanic isolation on this model?

Galvanic isolation (200 VDC between input, output and case) is essential to prevent ground loops and ensure electrical safety. It provides complete electrical separation between input and output circuits, offering enhanced protection against interference and grounding issues.

Is the Orion-Tr Smart inverter/charger compatible with smart alternators?

Yes, it is compatible with smart alternators (Euro 5 and Euro 6) thanks to an integrated engine-running detection mechanism. This prevents the starter battery from discharging when the alternator is not providing power.

What types of batteries can this device charge?

This inverter/charger is compatible with lead-acid and lithium batteries. It uses a 3-stage adaptive charging algorithm (bulk, absorption, float) that optimizes battery lifespan.

How does the 3-stage adaptive charging algorithm work?

The algorithm comprises three stages:

Bulk: The charger delivers as much charging current as possible to quickly recharge the batteries. Absorption: The controller switches to constant voltage mode when the battery voltage reaches the absorption voltage setting. For lead-acid batteries, the duration is automatically adjusted after a partial discharge. For lithium batteries, the duration is fixed (2 hours by default). Float: A float voltage is applied to the battery to maintain it in a fully charged state. These parameters are configurable via the VictronConnect application.

Is it possible to connect multiple Orion-Tr Smart units in parallel?

Yes, an unlimited number of Orion-Tr Smart 24/12-30A units can be connected in parallel to increase the total output current.

How can I configure and monitor the inverter/charger?

The inverter/charger is configured and monitored via the VictronConnect app, accessible via Bluetooth Smart from a smartphone, tablet, or other compatible device. The app allows you to adjust settings, monitor the charger, and update it if new software features become available.

What electronic protections are built into this device?

The Orion-Tr Smart 24/12-30A is equipped with extensive electronic protections, including:

Overheat protection (with power reduction if ambient temperature is high).Overload protection.Short-circuit protection.Overheat protection of connectors.

How to physically install the inverter/charger?

The device must be mounted vertically on a non-flammable surface, with the power terminals facing downward. It is recommended to leave a minimum clearance of 10 cm above and below the product for optimal cooling. Mount it near the battery, but never directly above it to avoid damage from battery gases.

Which types of cables are recommended for connections?

Use flexible multi-strand copper cables for battery connections. Individual strand diameter must not exceed 0.4mm (or 0.125mm² / AWG26). For example, a 16mm² cable should have at least 122 strands (class 5 or higher per VDE 0295, IEC 60228, and BS6360).

Do we need to install a fuse for this inverter/charger?

Yes, the installation must include a fuse in accordance with Victron Energy’s specific recommendations to ensure system safety.

Does the inverter/charger have a remote on/off function?

Yes, a remote on/off function is available. A switch or relay contact can be connected to a two-pole connector to turn the device on or off. It can also be controlled via the VictronConnect app.

What is the operating temperature range of the Orion-Tr Smart 24/12-30A?

The operating temperature range of the device is -20 to +55 °C. A power reduction of 3% per °C is applied above 40°C.

Is the product waterproof or moisture-resistant?

The inverter/charger has an IP43 protection rating, provided the installation is carried out with the screw terminals facing downward. It can tolerate up to 95% maximum humidity without condensation.

Is specific tooling required to connect the cables?

No, the inverter/charger is equipped with screw terminals, which means no specific tools are required for cable installation.

Is the product protected against reverse polarity?

No, the product is not protected against reverse polarity. It is imperative to check the polarity before and during the battery connection to avoid damaging the device.
