LUX SL180, LED pás, CRGBW, 200 mm

The Garmin LUX SL180 LED strip provides a full CRGBW color spectrum, including cool white, red, green, blue, and warm white. It also features tunable white lighting, allowing color temperature adjustment from 2700K to 6500K.

Yes, the Garmin LUX SL180 LED strip has an IP68 protection rating, making it suitable for both indoor and outdoor installations, including damp areas. However, it is not designed for continuous immersion in water.

The Garmin LUX SL180 light bar has a length of 200 mm.

Yes, the Garmin LUX SL180 LED strip is made from UV-resistant material. However, it is recommended not to install it in areas exposed to direct strong sunlight.

Yes, the LED strip can be bent to a minimum radius of 50 mm, but only along the vertical axis. Bending along the horizontal axis or twisting it must be avoided to prevent product damage.

For installation, ensure the boat's electrical power is disconnected or isolated. Clean the mounting surface thoroughly with isopropyl alcohol (IPA) to remove dust and dirt. Remove the 3M adhesive backing and press the light strip firmly into place, applying pressure only to the edges and not the LEDs. Allow the adhesive to cure for 24 hours before turning on the light.

Yes, it is strongly recommended that a qualified professional performs the electrical and mechanical installation of the Garmin LUX SL180 LED strip to ensure proper and safe installation.

For outdoor installations in wet areas or for tight bends, it is recommended to use mechanical fasteners (mounting clips) in addition to the 3M adhesive layer. These clips should be placed every 25 to 30 cm and/or on each side of a bend.

No, the Garmin LUX SL180 light strip is supplied in pre-cut and factory-sealed lengths to meet IP68 standards. It is imperative not to cut the light strip, as this would void its waterproofing and warranty.

During installation, carefully unroll the LED strip from the reel to prevent it from falling or twisting. Do not apply pressure to the LED area; only press on the edges of the strip. Do not pull, stretch, twist, or bend the strip along the horizontal axis. For lengths over one meter, it is recommended to use two people.

The Garmin LUX SL180 light bar is designed to be used exclusively with Lumishore LUX light bar control modules. It must not be connected to other third-party lighting control products or autopilot systems, as this may cause malfunction and void the warranty.

The Garmin LUX SL180 light bar requires an input voltage between 23 and 25V. It must be used exclusively with Lumishore LUX light bar control modules.

No, the Garmin LUX SL180 light bar must not be connected directly to a power source. It must be connected to a Lumishore LUX light bar driver module, which provides the correct voltage and control.

The warranty for the Garmin LUX SL180 LED strip is three years from the original purchase date, covering manufacturing defects.

The warranty may be voided in case of misuse, abuse, incorrect installation, negligence, improper shipping, damage caused by disasters (e.g., fire, flood, storm, and lightning), installation by unqualified personnel, unauthorized repair or modification, or unapproved installations. Use with third-party autopilots other than Lumishore LUX will also void the warranty.

The Garmin LUX SL180 light strip has a power consumption of 5 watts per meter.

The LUX SL180 LED strip is versatile and can be installed under gunwales, furniture, behind panels, or in other interior and exterior areas to create ambient or accent lighting.

The LED strip is equipped with a 3M adhesive backing for initial attachment. For enhanced security, especially in outdoor or damp areas, the use of stainless steel screw-mounted mounting clips is recommended as an additional measure.

The Garmin LUX SL180 light bar is primarily designed as an ambient and accent lighting solution for boats, offering a full CRGBW color spectrum and tunable white lighting.

The CRGBW lighting (cool white, red, green, blue, warm white) offers maximum flexibility to create various lighting moods. It allows not only vibrant colors but also pure white and warm white, providing a full range of lighting options to suit all situations and preferences.
