LUX SL180, Strip Light, CRGBW, 3000mm - Garmin image 1

Point relais offert dès 150€ en France
Retrait chez Skysat possible

Installation sur mesure

Faites confiance à Skysat pour installer l'équipement à bord

Demander un devis

Installateurs autour de vous

grâce à notre réseau d'installateurs agréés

Trouvez un installateur

Service d'assistance

Optez pour une aide complémentaire à la pose

Ušetříte 10%

Garmin

010-04390-00

LUX SL180, LED pás, CRGBW, 3000 mm

La bande LED Garmin LUX SL180 CRGBW de 3000 mm offre un éclairage marine polyvalent avec spectre couleur complet et blanc tunable (2700K-6500K), dotée de 180 LED/m et d'une protection IP68. Conçue pour une découpe précise tous les 100 mm, elle s'adapte aux installations intérieures et extérieures (non submersibles), nécessitant un module Lumishore LUX Strip Light Driver. Le produit inclut un kit de scellement avec embouts et silicone pour les coupes, ainsi que des clips de fixation à vis.

Prix publicBénéficier du tarif pro

205,34€

205,34€ ~~229,99€~~

s DPH Doprava se vypočítá při platbě.

Skladem

Point relais offert dès 150€ en France
Retrait chez Skysat possible

Installation sur mesure

Faites confiance à Skysat pour installer l'équipement à bord

Demander un devis

Installateurs autour de vous

grâce à notre réseau d'installateurs agréés

Trouvez un installateur

Service d'assistance

Optez pour une aide complémentaire à la pose

Caractéristiques techniques

Typ výrobku	Bande lumineuse LED
Provozní napětí	10.5-31 VDC
Barva světla	CRGBW
Stupeň krytí IP	IP68
Kompatibilní s stmíváním	Oui
Délka pásku	3.0
Hustota LED / metr	180.0
Lepící podklad	Oui
Bend Radius Vertical	50
Cuttable Interval Mm	100
Diffuser Type	Sans points
Umístění instalace	Intérieur, Extérieur, Zones humides
Materiál	Matériau résistant aux UV
Max Current Consumption Per Meter 12v	0.6
Max Current Consumption Per Meter 24v	0.36
Typ montáže	Adhésif 3M, Clips de fixation, Attaches mécaniques
Spotřeba elektrické energie na metr	8.7
Odolnost vůči UV	Oui

Description détaillée

LED pás GARMIN LUX SL180 CRGBW o délce 3000 mm představuje flexibilní řešení pro osvětlení na moři s plným spektrem barev, navržené pro přizpůsobitelné osvětlení v různých námořních prostředích. Tento LED pás integruje LED CRGBW (studená bílá, červená, zelená, modrá, teplá bílá), které poskytují úplné barevné spektrum a nastavitelnou teplotu bílého světla od 2700 K do 6500 K.

Integrace a technické parametry

Díky 180 LED na metr poskytuje LUX SL180 rovnoměrné a intenzivní osvětlení po celé délce 3 metrů. Jeho konstrukce umožňuje snadné dělení každých 100 mm, což usnadňuje přesné přizpůsobení potřebám instalace. Součástí balení je těsnicí sada s koncovkami a silikonem pro udržení vodotěsnosti po dělení. Tento pás má stupeň krytí IP68, což jej činí odolným proti prachu a vodě pro použití na moři mimo trvalé ponoření. Je navržen pro napájení napětím 10,5 až 31 VDC prostřednictvím ovládacího modulu LUX Strip Light Driver, s maximální spotřebou proudu 0,6 A/m při 12 V a 0,36 A/m při 24 V. Průměrný příkon je 8,7 W/m.

Robustní konstrukce a univerzálnost instalace

GARMIN LUX SL180 je zcela zapouzdřená a vybavená difuzérem bez viditelných bodů, což zaručuje estetický vzhled. Je odolná vůči UV záření a testována v solné mlze, čímž zajišťuje dlouhou životnost i v náročných námořních podmínkách. Montáž je možná pomocí samolepicích pásků, dodaných šroubových svorek nebo volitelných nerezových spon. Tenký profil (šířka 14,5 mm) umožňuje diskrétní instalaci pod okraje paluby, do nábytku nebo za panely. Pás je stmívatelný a nabízí více možností ovládání, od jednoduchého momentového spínače až po plnou integraci s kompatibilními multifunkčními displeji (MFD), Lumishore displeji nebo chytrými zařízeními. V takovém případě je vyžadován Lumishore LUX Strip Light Driver pro ovládání spínačem a EOS-LUX Command Center pro pokročilé funkce MFD/chytrých zařízení. Jeden driver LUX Strip Light může řídit až 10 metrů LED pásů celkem, včetně modelů jako LUX SL90 pro jiné délky. Záruka na výrobek je 3 roky.

Documentations

Type	Nom
	Installation Guide - LUX SL90 & SL180 IP68 LED Strip Light

Avis de l'expert

Pol CONIN

Digitální manažer

« Technical analysis of the Garmin LUX SL180 CRGBW marine LED strip »

The Garmin LUX SL180 CRGBW LED strip is a flexible and technically advanced supplementary lighting solution for onboard integration. Its ability to provide a full CRGBW spectrum with tunable white from 2700K to 6500K makes it a relevant choice for varied lighting ambiences, ranging from functional lighting to ambient lighting. The integration of 180 LEDs per meter ensures homogeneous light diffusion, a key technical point to avoid unsightly "point" lighting effects often seen with lower-density strips.

The most strategic aspect of this product lies in its installation flexibility. The ability to cut it every 100 mm, combined with the provided sealing kit, allows precise adaptation of the length to the constraints of the boat's interior or exterior layouts, such as under lockers, along coamings, or for backlighting. However, it is imperative to note that the LUX SL180 requires the exclusive use of a Lumishore LUX Strip Light Driver module. This dependence on the Lumishore driver is a key factor to consider when planning the system, as it dictates the control architecture and limits compatibility with other third-party lighting systems. Although its IP68 rating makes it suitable for wet areas and water projection, it is crucial not to submerge it permanently and to respect the minimum bending radius of 50 mm on the vertical axis to avoid structural damage to the LEDs and circuit. Installation by two people is recommended for lengths exceeding 1 meter to ensure laying without twisting or bending.

Durabilité

Facilité d'installation

Rapport performance / prix

Paiement et sécurité

Vos informations de paiement et données sont traitées de manière sécurisée.

LUX SL180, LED pás, CRGBW, 3000 mm

205,34€

205,34€ ~~229,99€~~

Complétez votre installation avec des

Équipements complémentaires

Garmin

GPSMAP® 8410 – 10" zobrazovací jednotka s mapovou sadou světa

Ref : 010-02091-00

2.237,30€

2.237,30€ ~~2.939,00€~~

Garmin

GPSMAP® 8416xsv - kombinovaný GPS-sonar 16"

Ref : 010-02093-02

5.253,08€

5.253,08€ ~~6.829,00€~~

Questions fréquentes

Besoin d'aide ? Contactez-nous

What colors are available for the GARMIN LUX SL180 LED strip?

The GARMIN LUX SL180 LED light bar integrates CRGBW LEDs, meaning it provides a full color spectrum including cold white, red, green, blue, and warm white.

What is the length of the GARMIN LUX SL180 light bar?

The GARMIN LUX SL180 light bar has a length of 3000 mm, i.e. 3 meters.

How many LEDs does the LUX SL180 strip contain per meter?

The GARMIN LUX SL180 light strip is equipped with 180 LEDs per meter, ensuring uniform and vibrant illumination.

Can the LUX SL180 light strip be used outdoors or in wet areas?

Yes, the LUX SL180 LED strip is fully sealed and has an IP68 protection rating. It can be installed indoors or outdoors, including in damp areas, but is not designed for permanent submersion in water.

What is the color temperature range of white for the LUX SL180 strip?

The LUX SL180 LED light strip offers adjustable white temperature, ranging from 2700K (warm white) to 6500K (cool white).

What is the power consumption of the LUX SL180 LED light strip?

The maximum current consumption of the LUX SL180 LED strip is 0.6 A/m at 12 V and 0.36 A/m at 24 V. Its average power is 8.7 W/m.

What is the IP rating of the GARMIN LUX SL180 LED strip?

The GARMIN LUX SL180 light bar has an IP68 protection rating, making it resistant to dust and water, but not to permanent submersion.

Is the GARMIN LUX SL180 LED light bar UV-resistant?

Yes, the GARMIN LUX SL180 LED strip is made from UV-resistant materials. However, it is recommended not to install it in areas exposed to direct sunlight.

Can the GARMIN LUX SL180 light bar be cut to the desired length?

Yes, the LUX SL180 design allows for easy cutting every 100 mm to precisely fit your installation requirements. A sealing kit with end caps and silicone is provided to maintain watertight integrity after cutting.

What is the minimum allowed bend radius for the LUX SL180 light strip?

The LUX SL180 light strip has a minimum bending radius of 50 mm only in the vertical axis. It is imperative not to bend it in the horizontal axis or twist it.

How to prepare the surface before installing the LED strip with 3M adhesive?

Before using 3M adhesive, thoroughly clean the mounting surface with IPA (isopropyl alcohol) and ensure it is free of dust and dirt. Once the tape is in place, firmly press along the edges (without applying pressure to the LEDs) and allow the adhesive to cure for 24 hours before turning on the strip.

Is it recommended to use mechanical fasteners for installing the LED strip?

For outdoor installations in wet areas or if the tape is subjected to tight bending radii, it is strongly recommended to use mechanical fastenings in addition to the adhesive layer. Fixing clips should be placed every 25 to 30 cm and/or on each side of a bend.

What precautions should be taken when handling the light strip during installation?

Unroll the LED strip carefully from the reel to avoid it falling or twisting. Do not apply pressure on the LED area; press only the edges of the strip. Do not pull, stretch, twist, or bend the strip along its horizontal axis. For lengths over 1 meter, it is advisable to work with two people. Always lay the strip flat in a straight line to prevent creases or twists.

Who should carry out the electrical and mechanical installation of the LUX SL180 LED strip?

The electrical and mechanical installation of the LUX SL180 LED strip must be carried out by a qualified professional to ensure safety and compliance.

Should the boat's power supply be disconnected before installing the LED strip?

Yes, it is imperative to always ensure that the vessel's power source and the battery are disconnected or isolated before proceeding with the installation of the strip light.

Where should I not install the LUX SL180 LED strip?

Although the LED strip is UV-resistant, it must not be installed in areas of direct strong sunlight. Additionally, it is not designed to be permanently submerged in water.

What type of control module is required to operate the LUX SL180?

The LUX SL180 LED strip is designed for exclusive use with the LUX Strip Light Driver control module. It requires an input voltage of 10.5 to 31 VDC via this module.

Can I use the LUX SL180 LED strip with a lighting driver from another brand?

No, the LUX SL180 LED strip is specifically designed to operate only with LUX Strip Light Driver control modules. Connecting to third-party lighting control products or drivers is not supported and will void the warranty.

What is the warranty duration for the LUX SL180 LED strip?

The LUX SL180 LED strip carries a three-year warranty against manufacturing defects, starting from the original purchase date.

What can void the warranty of the LUX SL180 LED strip?

The warranty may be voided in case of misuse, abuse, incorrect installation, negligence, damage caused by disasters (fire, flood, lightning), installation by unqualified personnel, unauthorized repair or modification, or non-approved installations. Using the LED strip with third-party drivers also voids the warranty.
