LUX SL180, Strip Light, CRGBW, 700mm - Garmin image 1

Point relais offert dès 150€ en France
Retrait chez Skysat possible

Installation sur mesure

Faites confiance à Skysat pour installer l'équipement à bord

Demander un devis

Installateurs autour de vous

grâce à notre réseau d'installateurs agréés

Trouvez un installateur

Service d'assistance

Optez pour une aide complémentaire à la pose

Ušetříte 12%

Garmin

010-04368-00

LUX SL180, LED pás, CRGBW, 700 mm

Conçue pour l'éclairage d'ambiance marin, la bande LED Garmin LUX SL180 CRGBW de 700mm offre une illumination CRGBW à spectre complet.

Certifiée IP68 et résistante aux UV/sel, elle nécessite le module pilote Lumishore LUX Strip Light Driver pour fonctionner.

Le produit inclut le revêtement adhésif 3M et les clips de fixation à vis. Il peut être coupé tous les 100 mm et scellé avec le kit de scellement inclus.

Prix publicBénéficier du tarif pro

61,40€

61,40€ ~~69,98€~~

s DPH Doprava se vypočítá při platbě.

Skladem

Point relais offert dès 150€ en France
Retrait chez Skysat possible

Installation sur mesure

Faites confiance à Skysat pour installer l'équipement à bord

Demander un devis

Installateurs autour de vous

grâce à notre réseau d'installateurs agréés

Trouvez un installateur

Service d'assistance

Optez pour une aide complémentaire à la pose

Caractéristiques techniques

Typ výrobku	Bande lumineuse
Provozní napětí	23-25
Typická spotřeba elektrické energie	5 W par mètre
Barva světla	Blanc froid, Rouge, Vert, Bleu, Blanc chaud
Stupeň krytí IP	IP68
Kompatibilní s stmíváním	Oui
Délka pásku	0.7
Hustota LED / metr	180.0
Lepící podklad	Oui
Compatible Command Center	Lumishore EOS-LUX Command Center
Control Methods	Interrupteur momentané, Écrans multifonctions (MFD), Écrans Lumishore dédiés, Appareils intelligents
Cuttable	Non
Prostředí instalace	Intérieur, Extérieur, Zones humides
Minimum Bend Radius	50
Permanently Submersible	Non
Required Driver Model	Lumishore LUX Strip Light Driver
Odolnost vůči UV	Oui
Warranty Duration Years	3
White Color Temperature Range	2700-6500

Description détaillée

Pásová LED Garmin LUX SL180 CRGBW o délce 700 mm je navržena pro osvětlení námořních prostor. Nabízí plnospektrální osvětlení CRGBW (studený bílý, červený, zelený, modrý, teplý bílý) s nastavitelnou teplotou bílého světla od 2700 K do 6500 K. Tento model, měřící 700 mm na délku, obsahuje 180 LED CRGBW na metr, což zajišťuje rovnoměrné a intenzivní osvětlení na palubě. Spotřeba energie činí 5 wattů na metr a pracuje s napájecím napětím 23 až 25 V.

Integrace a ovládání

Pás LUX SL180 je určen výhradně k použití s ovládacím modulem Lumishore LUX Strip Light Driver, což je nezbytné pro jeho správné fungování a pro zachování platnosti záruky. Toto omezení řadí LUX SL180 mezi součásti širšího ekosystému osvětlení Lumishore, nyní pod značkou Garmin. Ovládání osvětlení lze provádět prostřednictvím okamžitého spínače připojeného k ovladači, nebo pokročilým způsobem integrací s kompatibilními multifunkčními displeji (MFD), specializovanými displeji Lumishore nebo chytrými zařízeními, přičemž je vyžadován řídicí systém Lumishore EOS-LUX Command Center.

Instalace a odolnost

Díky krytí IP68 je pásová LED Garmin LUX SL180 odolná proti prachu a dočasnému ponoření, což ji činí vhodnou pro instalace uvnitř i venku nad čárou ponoru. Je vyrobena z materiálu odolného vůči UV záření a slané mlze, což zaručuje její dlouhou životnost v námořním prostředí. Instalace je usnadněna pomocí samolepícího pásu 3M a dodaných šroubových spon. Je nezbytné dodržet minimální poloměr ohybu 50 mm ve vertikální ose a nikdy neohýbat pás ve vodorovné ose ani jej kroutit. Pás lze stříhat v krocích po 100 mm a utěsnit pomocí dodaného těsnicího kitu. Tento výrobek je opatřen tříletou zárukou.

Documentations

Type	Nom
	Installation Guide - LUX SL180 CRGBW 700mm LED Strip Light (EN)

Avis de l'expert

Pol CONIN

Digitální manažer

« Garmin LUX SL180 marine ambient lighting: CRGBW integration and performance »

The Garmin LUX SL180 CRGBW 700mm LED strip is part of the Lumishore ecosystem, now integrated into Garmin’s product range, and provides a sophisticated accent lighting solution for marine environments. Its practical value lies in creating customizable lighting ambiences thanks to its full-spectrum CRGBW capability and tunable white LEDs, ideal for gangways, under furniture, or behind ceiling panels where discreet yet effective lighting is required.

Integration is critical: this LED strip is not a standalone solution. It requires the Lumishore LUX Strip Light Driver module, which converts the input voltage and manages CRGBW colorimetry. This dependency on the driver is a key consideration during installation planning, as it involves an additional component and a specific connection, unlike more generic LED strips that can connect directly to a 12/24V source. For outdoor installations or in damp areas, using the provided mounting clips in addition to the 3M adhesive is recommended to ensure durability. It is essential to respect the minimum 50mm vertical-axis curvature and avoid any twisting or horizontal bending to prevent compromising the strip’s integrity.

This product is particularly suited to owners seeking a discreet accent lighting solution controllable via their compatible Garmin MFD or a Lumishore EOS-LUX Command Center. It is not designed for permanent submersion and can be cut every 100mm and sealed with the included sealing kit. Its UV and salt-mist resistance ensures good long-term performance, provided it is not exposed to direct, strong sunlight.

Durabilité

Facilité d'installation

Rapport performance / prix

Paiement et sécurité

Vos informations de paiement et données sont traitées de manière sécurisée.

LUX SL180, LED pás, CRGBW, 700 mm

61,40€

61,40€ ~~69,98€~~

Complétez votre installation avec des

Équipements complémentaires

Garmin

GPSMAP® 8410 – 10" zobrazovací jednotka s mapovou sadou světa

Ref : 010-02091-00

2.237,30€

2.237,30€ ~~2.939,00€~~

Garmin

GPSMAP® 8416xsv - kombinovaný GPS-sonar 16"

Ref : 010-02093-02

5.253,08€

5.253,08€ ~~6.829,00€~~

Garmin

TD 50, 5" dotykový displej

Ref : 010-02139-10

507,24€

507,24€ ~~689,00€~~

Questions fréquentes

Besoin d'aide ? Contactez-nous

What is the length of this Garmin LUX SL180 LED light strip?

The Garmin LUX SL180 light strip measures 700mm in length.

What lighting colors are available with the LUX SL180 strip?

The LUX SL180 LED light strip provides a full CRGBW spectrum, including cool white, red, green, blue, and warm white.

Is it possible to adjust the color temperature of the white on this LED strip?

Yes, the white color temperature is adjustable from 2700K (warm white) to 6500K (cool white).

Is this LED light strip UV-resistant?

Yes, the LUX SL180 LED light strip is made from UV-resistant material.

Can the Garmin LUX SL180 light strip be cut to fit a specific length?

No, the LUX SL180 LED strip is supplied in pre-defined lengths sealed at the factory to meet IP68 standards. It must not be cut.

Where can the Garmin LUX SL180 LED strip be installed?

The LUX SL180 LED light strip is fully sealed with an IP68 rating, meaning it can be installed indoors or outdoors, including in wet areas. However, it is not designed for permanent immersion in water.

How to mount the LUX SL180 LED strip?

The light strip can be mounted in several ways:

Using its integrated 3M adhesive tape after thoroughly cleaning the surface. For outdoor installations, wet areas, or tight bends, it is recommended to use additional mechanical fasteners, placed every 25 to 30 cm and/or on each side of a bend. Stainless steel mounting clips for narrow mounting channels are also available as an option from Lumishore.

Are there any precautions to take when handling or installing the LED strip?

Yes, several precautions must be observed:

Always ensure the vessel's power source is disconnected or isolated before installation.The strip must only be bent along the vertical axis with a minimum radius of 50 mm.It is imperative not to bend it along the horizontal axis or twist it.Do not apply pressure on the LED area, only on the edges of the strip.For lengths over one meter, it is recommended to use two people for installation.

What is the minimum bending radius allowed for this LED strip?

The minimum allowed bending radius for the LUX SL180 light strip is 50 mm, and only along the vertical axis. Bending along the horizontal axis or twisting the strip is strictly prohibited.

Should the surface be cleaned before installing the light strip with the 3M adhesive?

Yes, it is imperative to thoroughly clean the mounting surface using IPA (isopropyl alcohol) and ensure it is free of dust and dirt before applying the 3M adhesive tape. Allow the adhesive to cure for 24 hours before powering on the tape.

Which module is required to operate the Garmin LUX SL180 light strip?

The LUX SL180 LED light strip is specifically designed to be used exclusively with the Lumishore LUX Strip Light Driver module. This module is mandatory for proper operation and to maintain warranty validity.

Can this LED strip be connected to other lighting control systems besides Lumishore's?

No, the LUX SL180 LED strip must be connected exclusively to Lumishore LUX Strip Light Driver modules. Using third-party products or drivers is not only discouraged but will also void the warranty.

How to control the lighting of the LUX SL180 strip?

Lighting can be controlled in several ways:

Via a momentary switch connected to the Lumishore LUX Strip Light Driver module. More advanced integration with compatible multifunction displays (MFD), dedicated Lumishore screens, or smart devices requires the Lumishore EOS-LUX Command Center.

What is the required input voltage for the LUX SL180 LED strip?

The LUX SL180 LED strip requires an input voltage of 23 to 25V. It must only be used with Lumishore LUX Strip Light Driver modules, as these are designed to provide this specific voltage range.

Is this LED strip compatible with Garmin multifunction displays (MFD)?

Yes, the lighting control of the LUX SL180 strip can be performed by integration with compatible multifunction displays (MFD), including potentially Garmin units, provided the Lumishore LUX Strip Light Driver module is used and, for advanced control, the Lumishore EOS-LUX Command Center.

What is the warranty duration for the Garmin LUX SL180 lighting system?

The Garmin LUX SL180 lighting system is covered by a three-year warranty from the original purchase date for manufacturing defects.

What conditions can void the warranty for the LED light strip?

The warranty will be void in the following cases:

Misuse, abuse, or incorrect installation.
Negligence or damage caused by disasters (fire, flood, storm, lightning).
Installation by unqualified personnel.
Unauthorized repair or modification.
Installations not approved or non-compliant with installation and use guidelines.
Use with third-party autopilots not Lumishore.

Is the warranty valid if the LED strip is used with an autopilot from another brand?

No, the warranty will be void if the LUX SL180 LED strip is used with third-party drivers. It is designed to operate exclusively with the Lumishore LUX Strip Light Driver module.
