Garmin

010-04430-00

LUX SNL180, neonový LED pásek Superbright, 2300 mm

Conçue pour l'éclairage marin, la bande LED Garmin LUX SNL180 de 2300mm offre une illumination CRGBW sans points, avec 180 LEDs/m et une protection IP67. Ce modèle, partie de la gamme Lumishore LUX, nécessite un module pilote Lumishore LUX Strip Light Driver pour son fonctionnement et son contrôle étendu. Elle est fournie avec des clips de fixation en acier inoxydable.

Prix publicBénéficier du tarif pro

192,06€

192,06€ ~~209,99€~~

s DPH Doprava se vypočítá při platbě.

Skladem

Point relais offert dès 150€ en France
Retrait chez Skysat possible

Installation sur mesure

Faites confiance à Skysat pour installer l'équipement à bord

Demander un devis

Installateurs autour de vous

grâce à notre réseau d'installateurs agréés

Trouvez un installateur

Service d'assistance

Optez pour une aide complémentaire à la pose

Caractéristiques techniques

Typ výrobku	Bande LED flexible
Provozní napětí	24 V
Typická spotřeba elektrické energie	11.5 W
Barva světla	Multicolore (RVB) et Blanc
Stupeň krytí IP	IP67
Kompatibilní s stmíváním	Oui
Bending Axis	Latéral uniquement
Can Be Cut	Non
Compatible Driver Required	Lumishore LUX Strip Light Driver Module
Prostředí instalace	Intérieur ou extérieur, zones humides (non submersible)
Minimum Bend Radius	120
Mounting Method	Clips à visser
Rozsah provozního napětí	23 - 25
Spotřeba elektrické energie na metr	5
Odolnost vůči UV	Oui
Warranty Period Years	3

Description détaillée

Určena pro osvětlení lodního interiéru a obrysů, neonový LED pásek Garmin LUX SNL180 o délce 2300 mm (referenční číslo 010-04430-00) představuje flexibilní osvětlovací řešení poskytující homogenní osvětlení bez bodových zdrojů. Tento model obsahuje 180 LED CRGBW na metr, umožňující plný barevný spektra (červená, zelená, modrá) a studené i teplé bílé světlo s nastavitelnou barevnou teplotou od 2700K do 6500K. Jeho flexibilní konstrukce umožňuje instalaci kolem zakřivených povrchů, ideální pro lodní boky, stropy kabin nebo T-topy, s minimálním poloměrem ohybu 120 mm (pouze boční ohyb).

Integrace a technické parametry

Neonový pásek LUX SNL180 je navržen výhradně pro použití s řídicími moduly Lumishore LUX Strip Light Driver a nesmí být připojen k jiným externím ovladačům. Tato závislost zajišťuje optimální integraci v rámci ekosystému Lumishore, umožňující ovládání prostřednictvím momentálního spínače nebo, s přídavným řídicím centrem EOS-LUX, pokročilé řízení prostřednictvím multifunkčních displejů (MFD), displejů Lumishore nebo chytrých zařízení. Každý metr spotřebuje 5 wattů při vstupním napětí 23–25 V, čímž zajišťuje konstantní světelný výkon a cílenou energetickou správu.

Odolnost a instalace

Vyroben z materiálů odolných proti UV záření a testován v solné mlze, neonový pásek LUX SNL180 disponuje plnou zalitím a stupněm krytí IP67, což jej činí vhodným pro vnitřní i venkovní instalace, včetně vlhkých prostor, nikoli však pro trvalé ponoření. Instalace se provádí pomocí dodávaných nerezových spon, zajišťujících bezpečné upevnění. Na rozdíl od běžných LED pásků je tento model dodáván v předem stanovených délkách a továrně zalitý, aby byla zachována těsnost IP67, a nesmí být zkracován.

Documentations

Type	Nom
	Installation Guide - LUX SNL180 2300mm Flexible Light Installation Guide

Avis de l'expert

« CRGBW contour lighting: integration of the LUX SNL180 »

The Garmin LUX SNL180 LED strip represents a differentiated contour lighting option for demanding marine installations. Its primary functional value lies in its ability to produce a homogeneous, dot-free CRGBW light, a major aesthetic advantage over traditional LED strips where individual light points may be visible. This feature makes it particularly suitable for creating sophisticated ambiances in cockpits, cabin interiors, under coamings, or along side decks, where soft, diffused lighting is desired.

Installing this 2300mm model requires mandatory integration into the Lumishore LUX ecosystem via a Lumishore LUX Strip Light Driver control module. This dependency must be considered during the electrical system design phase, as it involves a deliberate choice for this specific architecture. While physical mounting with the supplied clips is straightforward, handling strips of this length (>1m) requires assistance from a second person to avoid twisting or damaging the strip, given its minimum bending radius of 120mm and the prohibition against bending it vertically or cutting it. Its IP67 rating, UV resistance, and salt spray resistance ensure good durability in marine environments for applications excluding permanent submersion.

Choosing the LUX SNL180 is relevant for owners seeking an integrated lighting solution offering full colorimetric flexibility and a high-end light finish. It stands out from more basic LED solutions due to its illumination quality and robustness for marine environments, provided the investment in the associated Lumishore control system is accepted.

Durabilité

Facilité d'installation

Rapport performance / prix

Paiement et sécurité

Vos informations de paiement et données sont traitées de manière sécurisée.

LUX SNL180, neonový LED pásek Superbright, 2300 mm

192,06€

192,06€ ~~209,99€~~

Questions fréquentes

Besoin d'aide ? Contactez-nous

What is the exact length of the GARMIN LUX SNL180 light strip?

The GARMIN LUX SNL180 light strip has a length of 2300 mm.

What are the color and white temperature options available with this LED strip?

The LUX SNL180 strip integrates 180 CRGBW LEDs per meter, providing a full spectrum of colors (red, green, blue) as well as cool and warm whites. The color temperature is adjustable from 2700K to 6500K.

Is the GARMIN LUX SNL180 LED light bar waterproof and suitable for outdoor installation?

Yes, the LUX SNL180 band is fully sealed and has an IP67 protection rating. It can be installed indoors or outdoors, including in damp areas. However, it is not designed for permanent submersion in water.

What type of lighting does the GARMIN LUX SNL180 strip offer?

The LUX SNL180 strip is a flexible neon-style lighting solution designed for marine ambient and contour lighting. It provides uniform illumination without visible hotspots.

What is the power consumption of the LUX SNL180 LED light strip?

Each meter of the LUX SNL180 strip consumes 5 watts. For a 2300mm strip, the total consumption is therefore 11.5 watts.

Is the tape material UV-resistant?

Yes, the flexible neon light strip is made from UV-resistant materials. However, it is recommended not to install it in areas exposed to strong direct sunlight.

What precautions should be taken before starting the installation of the LUX SNL180 strip?

Before any installation, it is essential to ensure that the vessel's power source and battery are disconnected or isolated. It is also recommended that a qualified professional performs the electrical and mechanical installation.

Can I cut the Garmin LUX SNL180 LED light strip to fit a specific length?

No, the flexible neon light strip is supplied in ready-to-use lengths sealed at the factory to meet IP67 standards. Cutting the strip is strictly prohibited, as this would void the waterproofing and warranty.

What is the minimum allowable bend radius for the LUX SNL180 LED light strip?

The LUX SNL180 light strip has a minimum bending radius of 120 mm. It is critical to note that bending must only be performed along the lateral axis. Do not bend it along the vertical axis or twist it.

How is the LUX SNL180 LED strip fixed during installation?

The flexible neon strip is installed using the supplied stainless steel clips. These clips are screwed into place, then the strip is simply pushed into the clips until a 'click' is heard, confirming secure attachment. It is recommended to use multiple clips around tight bends to ensure proper conformity and prevent lifting.

How to handle the light bar during installation to avoid damaging it?

To avoid damaging the light strip:

Always carefully unroll it along its full length; do not lift it by a single end. Do not drop it or allow it to twist during installation. Do not apply excessive pressure. Do not pull, stretch, twist, or bend it vertically. For lengths over 1 meter, it is recommended to use two people for installation.

Is it mandatory to have the LUX SNL180 L-band installed by a professional?

Yes, the installation instructions state that a qualified professional must carry out the electrical and mechanical installation of the LUX SNL180 LED strip to ensure proper installation and warranty validity.

Which modules are required to operate the GARMIN LUX SNL180 LED light strip?

The GARMIN LUX SNL180 light strip is specifically designed to operate in conjunction with Lumishore LUX Strip Light Driver modules. It must be connected only to these modules.

Can I use lighting controllers from other brands with the LUX SNL180 strip?

No, it is essential not to connect the LUX SNL180 LED strip to third-party lighting controllers or autopilots. It is designed to operate exclusively with Lumishore LUX Strip Light Driver modules. Using third-party products will void the warranty.

How to control the lighting of the LUX SNL180 strip once installed?

The LUX SNL180 L-band control can be performed in several ways:

Via a momentary switch. With the addition of an EOS-LUX control unit, advanced management is possible via multifunction displays (MFD), Lumishore screens, or smart devices.

What is the required input voltage range for the LUX SNL180 LED strip?

The LUX SNL180 LED strip requires an input voltage between 23 and 25V. It must only be used with Lumishore LED strip driver modules to ensure correct voltage and proper operation.

What is the warranty duration for the GARMIN LUX SNL180 LED light bar?

The GARMIN LUX SNL180 LED bar is covered by a three-year warranty from the original purchase date against manufacturing defects.

What conditions can void the warranty of the LUX SNL180 LED strip?

The warranty for the LUX SNL180 strip may be voided in the following situations:

Improper use or abuse of the product. Incorrect or negligent installation. Damage caused by disasters (fire, flood, storm, lightning). Installation by unqualified personnel. Unauthorized repair or modification. Unapproved installations or non-compliance with installation, maintenance, and usage guidelines. Use with third-party controllers or autopilots not approved by Lumishore.

Is the product delivered with the necessary mounting clips?

Yes, the LED strip comes with the stainless steel clips required for installation. Suitable screws for securing the clips are also required and must be used to ensure full engagement of the clip on the strip.

What type of marine environment is this product intended for?

The GARMIN LUX SNL180 LED light strip is specifically designed for marine ambient and contour lighting. Its robust design and IP67 rating make it suitable for indoor and outdoor marine environments, though it should not be permanently submerged.
