B175H-W 1000W D/T Through-Hull Transducer Wide Beam Transducer Angle 20°

The Raymarine B175H-W is a 1000W through-hull transducer featuring high-frequency CHIRP technology. It is designed for depth and temperature (D/T) detection and features a wide beam (W) with a 20° tilt compensation angle to adapt to sloped hulls.

This Raymarine B175H-W transducer has an output power of 1000 watts (1 kW). This high power enables effective penetration at significant depths, improving detection performance.

The "D/T" designation means the transducer can measure both depth (Depth) and water temperature (Temperature). It provides these two essential data points to your depth sounder or compatible multifunction display system.

The "W" (Wide) designation indicates that this transducer emits a constant wide beam across the entire high-frequency CHIRP range. This significantly increases the coverage beneath the boat, enabling better detection of fish and underwater structures over a larger area, particularly useful for sport fishing.

The Raymarine B175H-W uses CHIRP high-frequency technology. This technology sends a frequency sweep over a wide band rather than a single fixed frequency, improving target separation and image clarity compared to traditional transducers.

Les avantages de la technologie CHIRP haute fréquence incluent :

Une séparation des cibles supérieure, permettant de distinguer les poissons individuels ou les bancs de poissons.Une clarté d'image améliorée, offrant une représentation plus détaillée du fond marin et des structures.Une meilleure pénétration et détection dans des profondeurs variées.

Yes, with its 1000W power and high-frequency CHIRP technology, the Raymarine B175H-W is well suited for deep-sea fishing. It provides effective penetration and precise target detection in significant depths.

This is a through-hull depth sounder, meaning it is installed by drilling a hole through the boat's hull and securing it from the inside. This installation type ensures optimal hydrodynamic performance and reliable readings even at high speeds.

Through-hull transducers, like the B175H-W, offer several advantages over transom-mount models:

Superior hydrodynamic performance, reducing drag. No turbulence around the transducer, ensuring more reliable readings at high speed. A more robust and permanent installation.

The 20° angle of the transducer is an integrated compensation angle. It is designed to suit boat hulls with a deadrise angle between 16 and 24 degrees. This angle keeps the transducer beam directed vertically toward the seabed, ensuring accurate and optimized readings.

This transducer is specifically designed for installation on hulls with a deadrise angle (hull angle at installation point) between 16 and 24 degrees. The 20° transducer compensation angle ensures the beam is correctly aligned.

Yes, as a through-hull transducer, installation requires drilling a hole in the boat’s hull to allow the transducer body and its cable to pass through. It is recommended to have a professional perform the installation to ensure proper sealing.

The Raymarine B175H-W transducer is compatible with Raymarine sounder and multifunction systems that support CHIRP technology, such as the Axiom or Element series. It integrates seamlessly with these platforms to deliver optimal performance.

Yes, this transducer can be compatible with competing systems such as Garmin or Simrad, provided these systems support Airmar 1000W CHIRP transducers. It is important to verify the compatibility specifications of your device and ensure the connector is suitable or that an adapter is available.

The Raymarine B175H-W transducer is designed to integrate with Raymarine systems compatible with CHIRP. The connector type is specific to the Raymarine brand to ensure optimal connection. For compatibility with other brands, an adapter cable may be required if the system supports Airmar CHIRP 1000W transducers.

No, this transducer is not compatible with all CHIRP fishfinders. It is specifically designed for CHIRP systems that support 1000W transducers. It is critical to verify the power and CHIRP compatibility of your fishfinder before purchasing.

Yes, the Raymarine B175H-W transducer is designed to withstand harsh marine environments. As a Raymarine product, it is built with durable materials to ensure long service life and reliable performance at sea.

The Raymarine B175H-W is a high-performance 1000W transducer using CHIRP technology, making it a top-tier piece of equipment commonly used by demanding sailors and anglers. Its design and technical features are engineered to deliver reliable and precise performance.

La principale différence réside dans l'angle du faisceau. Le B175H-W (Wide) offre un faisceau large constant sur toute la plage de fréquences CHIRP haute, augmentant la couverture sous le bateau. Un transducteur B175H standard (sans le 'W') aura un faisceau plus étroit, ce qui peut être préférable pour une détection très précise directement sous le bateau, mais avec une couverture latérale réduite.
