Raymarine

R70524

Metal mounting bracket kit for AXIOM 7

Designed for a secure installation of your AXIOM 7 multifunction display, the Raymarine R70524 metal mounting bracket kit is an essential accessory. This metal bracket ensures a durable and stable mounting, ideal for demanding marine environments. The AXIOM series, including the AXIOM 7, is a current and versatile range of multifunction displays. The kit includes the metal bracket and mounting hardware.

Retail priceBenefit from the professional rate

$107.17 USD

$107.17 USD ~~$113.00 USD~~

Shipping calculated at checkout.

In stock

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

thanks to our network of approved installers

Find an installer

Support service

Opt for additional installation assistance

Technical specifications

Mounting type	On bracket
Material	Metal
Color	Black
Compatible models	Raymarine AXIOM 7
Installation type	Screw-mounted
Display capacity	1 display
Kit contents	Mounting bracket, hardware, documentation
Product type	Mounting kit

Detailed description

The Raymarine R70524 metal mounting bracket kit is designed for secure installation of AXIOM 7 multifunction displays. This accessory provides a robust and reliable mounting solution for the display on a flat surface, offering an alternative to flush mounting.

Stability and Integration for AXIOM 7

Unlike standard mounts often made from composite materials, the metal bracket in the R70524 kit offers increased structural rigidity. This feature is critical in marine environments exposed to vibrations and shocks, ensuring the AXIOM 7 display remains securely in position even in rough seas. AXIOM chartplotters, operating under the LightHouse 4 operating system, are versatile MFDs known for their intuitive user interface and advanced navigation capabilities. This mount ensures reliable mechanical integration for the AXIOM 7, a compact and popular model in the AXIOM series, which also includes AXIOM+, AXIOM Pro, and AXIOM XL, available in various screen sizes to meet different installation and performance needs.

R70524 Mounting Kit: A Technical Choice

The R70524 kit is a technical solution for recreational boaters and professionals who prioritize durability and stability in their installations. It serves as an essential spare part or accessory for an alternative installation of the AXIOM 7, allowing for bracket mounting rather than flush mounting, which can be advantageous for open consoles or helm stations requiring screen orientation flexibility. The use of metal materials ensures superior resistance to mechanical stress and marine environmental factors, such as corrosion and temperature variations, compared to plastic mounts. This kit is specifically sized for the AXIOM 7, ensuring compatibility and optimal performance with this exact model.

Documentation

Type	Nom
	FR - Manuel d'utilisation - Kit de montage étrier métal pour AXIOM 7

Expert opinion

Pol CONIN

Digital Manager

« Stability and durability for Axiom 7 installation »

The R70524 metal bracket mounting kit is an essential solution for installations of the AXIOM 7 multifunction display where flush mounting is not feasible or desired. It is particularly relevant for open consoles, flybridges, or secondary helm stations, providing essential orientation flexibility for optimal visibility at various angles. Choosing a metal bracket is critical for applications where the display is subjected to significant mechanical stress, ensuring the MFD remains stable even in rough seas or during dynamic maneuvers. This robustness prevents unwanted movements that could compromise the readability of critical information or the integrity of the connections.

Compared to a plastic mount, the metal version of the R70524 offers better long-term material fatigue resistance and superior performance against marine environmental stresses. This ensures the longevity of your AXIOM 7 installation, reducing the risk of structural failure. It is imperative to note that this kit is specifically sized for the AXIOM 7 and will not fit other screen sizes in the AXIOM range (such as the 9 or 12-inch models), which require dedicated mounts due to weight and dimensional differences.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Metal mounting bracket kit for AXIOM 7

$107.17 USD

$107.17 USD ~~$113.00 USD~~

Frequently Asked Questions

Need help? Contact us

What is the main advantage of the metal material used for this mounting bracket?

The main advantage of the metal material is its increased structural rigidity and durability. Unlike brackets made from composite or plastic materials, the metal bracket offers better resistance to vibrations, shocks, corrosion, and temperature variations, which is essential in demanding marine environments.

In which situations is bracket mounting preferable to flush mounting?

Bracket mounting is advantageous for installations requiring screen orientation flexibility, such as on open consoles or helm stations. It allows adjustment of the Axiom 7 display viewing angle, which is not possible with flush mounting.

Is this mounting kit an original Raymarine part?

Yes, the R70524 metal bracket mounting kit is an official Raymarine accessory. It is designed to integrate perfectly with AXIOM 7 displays and ensure a secure and reliable installation according to the manufacturer's standards.

Does the R70524 kit include everything needed to install the AXIOM 7?

The R70524 kit includes the metal bracket and fasteners required to mount your AXIOM 7 display on a flat surface. It is designed to provide a complete solution for this type of installation.

How does this mount ensure screen stability in rough seas?

Thanks to its sturdy metal construction, this mount provides superior structural rigidity. This feature is essential to keep the AXIOM 7 screen firmly in place, even in rough seas, reducing vibrations and unwanted movements.

Is it possible to adjust the screen angle once mounted with this bracket?

Yes, one of the advantages of bracket mounting is the flexibility in orientation it provides. You can adjust the angle of the AXIOM 7 display to optimize visibility from different positions on the boat, which is particularly useful for open consoles or helm stations.
