SmartSolar MPPT VE.Can 150/70 Tr RS
In stock
Technical specifications
Technical specifications
| Product use | Solar charge controller for marine and land-based photovoltaic systems |
| Type de régulateur solaire | MPPT (Maximum Power Point Tracking) |
| Max charge current (A) | 70 |
| Nominal voltage | 12/24/48 (auto-select), 36 (manual) |
| Mppt maximale puissance | 4000 |
| Plage de tension d'entrée solaire | 0 to 145 V (max. 150 V absolute) |
| Absolute maximale solar tension | 150 |
| Tension de démarrage PV | Vbat + 5 |
| Max efficiency | 98 |
| Chimies de batterie supportées | Lead-acid (AGM, Gel, Flooded), Lithium (LiFePO4) |
| Nombre d'entrées panneaux solaires | 1.0 |
| Fonctionnement en parallèle supporté | Oui |
| Nombre d'étapes de charge | 3.0 |
| Compensation de température | Oui |
| Charge d'égalisation supportée | Oui |
| Wired network | VE.Can, VE.Direct |
| Compatible Bluetooth | Oui |
| Mobile app compatibility | Oui |
| Cooling method | Passive (fanless) |
| Protection features | Overheat protection,PV short-circuit protection,PV reverse polarity protection,PV reverse current protection |
| Display type | Optional (plug-in LCD) |
| Configuration software name | VictronConnect |
| Support mise à jour firmware | Oui |
| Mounting type | Surface mount |
| IP rating | IP43 (electronic components), IP22 (connection area) |
| Operating temperature range | -30 to +60 |
| Weight | 3 |
| Dimensions (W x H x D) | 250 x 215 x 95 |
| Code-barres du produit | SK-000046312 |
| Charge Algorithm Presets Count | 8 |
| Charge Algorithm Programmable | Yes |
| Fabricant | Victron Energy |
| Courant de court-circuit PV maximal | 50 |
| Product range | SmartSolar |
| Pv Operating Voltage Max | 145 |
| Marche/Arrêt à distance | Yes |
| Self Consumption 12v Ma | 35 |
| Self Consumption 48v Ma | 20 |
Detailed description
Detailed description
The Victron Energy SmartSolar MPPT 150/70 VE.Can charge controller (part number SCC115110511) is designed to optimize energy harvesting for marine and land-based photovoltaic installations. This controller integrates an ultra-fast maximum power point tracking (MPPT) algorithm, capable of improving energy production by up to 30% compared to PWM controllers, and 10% compared to slower MPPT units, particularly under cloudy conditions where light intensity fluctuates constantly. Its ability to detect the optimal maximum power point even under partial shading ensures consistent energy efficiency.
Performance and Efficiency of the SmartSolar MPPT 150/70 VE.Can
With a maximum conversion efficiency exceeding 98% and no cooling fan, the MPPT 150/70 VE.Can maintains stable performance. It is compatible with battery voltages of 12 V, 24 V, 36 V, and 48 V (auto-select, 36 V manual). Its nominal PV power reaches 1000 W at 12 V, 2000 W at 24 V, 3000 W at 36 V, and 4000 W at 48 V. The maximum PV open-circuit voltage is 150 V, with a maximum start-up and operating voltage of 145 V. The controller includes extensive electronic protection against overheating, PV short-circuit, PV reverse polarity, and PV reverse current, ensuring installation safety.
Connectivity and System Integration
The SmartSolar MPPT 150/70 VE.Can stands out for its comprehensive communication options. It features built-in Bluetooth Smart for configuration, monitoring, and updates via the VictronConnect app. The VE.Direct interface enables wired connection to a Color Control GX or other GX products, while the VE.Can port provides a solution for multi-controller systems, allowing synchronization of up to 25 units in a daisy-chain and individual monitoring via a GX device or the VRM portal. This advanced networking capability positions the 150/70 VE.Can as a flexible solution for complex energy systems, distinguishing it from SmartSolar models without a VE.Can interface, which do not offer this synchronized multi-controller scalability. It also supports recovery of fully discharged batteries, including Li-ion batteries with built-in disconnect function. A programmable relay and remote on/off function complete its system integration capabilities.
