SmartSolar MPPT 250/60-MC4
In stock
Technical specifications
Technical specifications
| Product use | Solar charge controller to maximize energy harvest and maintain battery health. |
| Type de régulateur solaire | MPPT |
| Max charge current (A) | 60 |
| Nominal voltage | 12 / 24 / 48 V (auto-select), 36 V (via software) |
| Mppt maximale puissance | 860 W (12V), 1720 W (24V), 2580 W (36V), 3440 W (48V) |
| Plage de tension d'entrée solaire | Vbat + 5 V to 245 V |
| Absolute maximale solar tension | 250 |
| Tension de démarrage PV | Vbat + 5 V |
| Max efficiency | >99 |
| Chimies de batterie supportées | Lead-acid (AGM, Gel, Flooded), Lithium-ion |
| Nombre d'entrées panneaux solaires | 2.0 |
| Fonctionnement en parallèle supporté | Oui |
| Nombre d'étapes de charge | 3.0 |
| Compensation de température | Oui |
| Charge d'égalisation supportée | Oui |
| Wired network | VE.Direct |
| Compatible Bluetooth | Oui |
| Mobile app compatibility | Oui |
| Cooling method | Passive (fanless) |
| Protection features | Overheat protection,PV short-circuit protection,PV reverse polarity protection,PV reverse current protection |
| Display type | None (optional plug-in LCD) |
| Configuration software name | VictronConnect |
| Support mise à jour firmware | Oui |
| Mounting type | Surface mount |
| IP rating | IP43 (electronic components), IP22 (connection area) |
| Operating temperature range | -30 to +60 |
| Weight | 3 |
| Dimensions (W x H x D) | 250 x 215 x 95 |
| Charge Algorithm Presets Count | 8 |
| Charge Algorithm Programmable | Yes |
| Support récupération batterie déchargée | Yes |
| Support capteur externe de tension et température | Yes |
| Compatible appareil GX | Yes |
| Internal Temp Sensor Included | Yes |
| Max Parallel Units | 10 |
| Mppt Advanced Detection Shading | Yes |
| Gain d'efficacité MPPT | Up to 30% (vs PWM), up to 10% (vs slower MPPT) |
| Remote on/off support | Yes |
Detailed description
Detailed description
Designed to maximize solar energy harvesting, the SmartSolar MPPT 250/60-MC4 charge controller from Victron Energy features ultra-fast MPPT technology. It automatically manages battery voltages of 12 V, 24 V, and 48 V, with a 36 V option via software tool, and delivers a nominal charging current of 60 A. This model stands out for its ability to optimize production even under cloudy skies, outperforming PWM controllers by 30 % and slower MPPT controllers by 10 %.
Advanced optimization and connectivity
The SmartSolar MPPT 250/60-MC4 can identify the optimal maximum power point (MPP) even with partial shading, avoiding lock-in on local MPPs. Its conversion efficiency exceeds 99 %, without requiring a cooling fan. Equipped with built-in Bluetooth Smart, it enables wireless configuration, monitoring, and updates via the VictronConnect app, as well as synchronization of up to 10 units for larger systems.
Built-in features and protections
This charge controller offers a flexible charging algorithm, fully programmable or selectable from eight presets via a rotary switch. It includes comprehensive electronic protections against overheating, PV short circuits, PV polarity reversal, and PV reverse current. A recovery function allows recharging of fully discharged batteries, including Li-ion batteries with built-in disconnection function. Connectivity is provided by a VE.Direct port for integration with GX devices, a programmable relay, and a remote on/off function. Compared to the 250/70 model in the same range, the 250/60 offers a nominal current capacity of 60 A versus 70 A, while retaining the same advanced tracking and management features.
