Active speaker for Ray 90/91 wireless

An active speaker, such as the Raymarine A80543, has built-in amplification. This means it does not require an external amplifier to operate, unlike a passive speaker which needs external amplification to produce sound. Integrating the amplifier reduces the load on the main VHF unit and ensures sufficient audio volume.

This active speaker provides several key advantages:

It extends the audio capabilities of your VHF system, enabling amplified and remote sound output. It ensures clear and distinct listening to VHF communications, even in noisy marine environments. It integrates its own amplification, reducing the load on the main VHF unit. It allows audio to be routed to areas away from the main helm (flybridge, cockpit, cabins) without requiring an additional external amplifier, simplifying integration and minimizing clutter. It provides constant monitoring of VHF channels.

The dimensions of the Raymarine active speaker A80543 are as follows:

Width: 104.3 mmHeight: 118.5 mmDepth: 30.6 mm

Yes, the Raymarine A80543 active speaker is specifically designed for marine environments. It is engineered to integrate with Raymarine marine communication systems and features waterproofing compliant with ingress protection standards.

Yes, the Raymarine A80543 active speaker is equipped with its own controls, allowing you to manage certain functions directly from the device.

Yes, the Raymarine A80543 active speaker is supplied with the mounting hardware required for installation.

The primary function of the A80543 active speaker is to extend and amplify the audio capabilities of Ray90 and Ray91 Raymarine DSC VHF systems. It allows audio to be routed to different areas of the vessel such as the flybridge, cockpit, or cabins, ensuring clear and distinct reception of VHF communications throughout the boat.

The Raymarine A80543 active speaker is specifically designed to be compatible with the Raymarine Ray90 and Ray91 DSC VHF radios.

No, this active speaker is specifically designed for Raymarine Ray90 and Ray91 DSC VHF radios and is not compatible with other VHF radio brands.

This speaker is designed to be installed in various areas of the vessel to relay audio. Typical locations include:

The flybridgeThe cockpitCabin areasAny zone remote from the main helm where clear audio is required.

The Raymarine A80543 active speaker requires a 12 V DC power supply. Refer to the installation manual for specific details on inline fuses and thermal circuit breakers.

Yes, to optimize wireless performance, follow the positioning guidelines specified in the installation manual. It is also advisable to conduct a site survey prior to installation to ensure the best conditions for wireless reception and transmission.

Yes, Raymarine recommends installation by a certified Raymarine installer. This ensures not only proper operation of the product but may also qualify you for enhanced warranty benefits.

During installation, it is important to follow EMC (Electromagnetic Compatibility) installation guidelines to minimize electrical and RF interference. This includes considerations for cable routing, the use of suppression ferrites, and connections to other equipment. Refer to the manual for detailed instructions.

A specific safe distance from a magnetic compass must be observed when installing the active speaker. This distance is specified in the product installation manual to prevent interference with the compass operation.

An installation certified by a Raymarine authorized installer may provide enhanced product warranty benefits. It is recommended to contact your Raymarine dealer for further details and to review the warranty document supplied with your product.

Yes, the Raymarine A80543 active speaker is generally supplied with the power cable required for connection to the vessel's electrical system.
