Passive speaker for Ray 90/91

The Raymarine A80542 passive speaker is an accessory designed to extend the audio range of Raymarine Ray90 and Ray91 DSC VHF radios. It provides an additional audio output, essential for optimizing communication clarity aboard, particularly in areas distant from the main handset.

The passive A80542 speaker is specifically designed to be compatible with Raymarine Ray90 and Ray91 DSC VHF radios. It ensures seamless integration and audio quality compliant with the brand's standards for these modular systems.

No, the A80542 speaker is a passive model. It draws its audio signal and amplification power from the main unit (Ray90 or Ray91 radio). This simplifies installation and wiring, as it does not require a separate power supply or amplifier.

The A80542 speaker provides clear playback of radio messages and DSC alerts in areas of the vessel that are distant from the main handset. It is particularly useful on cruising or fishing boats where communication must be audible from multiple listening stations, such as the flybridge, cockpit, or saloon.

A passive speaker, like the A80542, draws its audio signal and amplification power from the main unit it is connected to. An active speaker, on the other hand, requires a separate power supply and amplification to operate.

No, the passive speaker A80542 is specifically designed for Ray90 and Ray91 models to ensure seamless integration and optimal sound quality. It is not compatible with the Ray50, Ray60, Ray63, Ray70, or Ray73 series.

Yes, it is important to consider general speaker placement requirements, particularly to avoid radio frequency (RF) interference. The Ray90/Ray91 radio installation manual provides specific guidelines on mounting and cable routing.

To avoid RF interference, follow the installation guidelines provided in the product documentation. This includes considerations for cable routing and distance from other transmitting equipment.

While Raymarine products are designed for marine environments and meet water ingress protection standards, avoid high-pressure washing. High-pressure washing could lead to water intrusion and equipment failure.

No, the passive speaker A80542 has no built-in controls. It is designed to output audio from the Ray90 or Ray91 main unit, and settings such as volume are controlled via the VHF radio or its handsets.

The passive speaker A80542 integrates directly with the Ray90 and Ray91 VHF systems. It functions as an audio extension, drawing its signal and power from the radio's main unit, ensuring optimized compatibility and audio performance.

No, the passive A80542 speaker is designed to complement the main VHF system by providing additional audio output. It is particularly useful when the speaker integrated into the handset or base station is insufficient to cover all areas of the vessel.

The Raymarine A80542 speaker is positioned as a functional component required for users of Ray90 and Ray91 VHF radios who need extended audio coverage, particularly to ensure communication is audible from multiple listening stations aboard the vessel.

The passive speaker A80542 is designed to integrate with the base units of Ray90 and Ray91 VHF radios. It is not directly compatible with wireless handsets, as it is used to extend the audio output of the main station.

Yes, general wiring guidelines are provided in the Ray90/Ray91 installation documentation. These guidelines cover aspects such as cable types and lengths, routing, bend radius, strain relief, and cable shielding to ensure optimal performance and prevent interference.

The main advantage of a passive speaker like the A80542 is its ease of integration. It does not require a separate power supply or amplification, simplifying installation and wiring. It draws power directly from the main unit, ensuring optimized audio performance within the Raymarine ecosystem.

The passive A80542 speaker is designed to be mounted. Wiring speaker mounting instructions are included in the Ray90/Ray91 radio installation manual, detailing the steps required for proper mounting.

Yes, Raymarine VHF DSC radios' technical documentation includes a dedicated troubleshooting section for audio issues, specifically for passive speakers. This section aims to help resolve problems related to audio transmission or reception.
