Apsauga baterijai nuo žemo įtampos 12/24V 40A

The Samlex SB100 battery protector is an intelligent device designed to prevent excessive discharge of 12V or 24V batteries. It also protects connected electronic devices from voltage spikes, helping to extend the lifespan of the entire onboard power system.

Yes, the Samlex SB100 has automatic system voltage detection, allowing it to operate with either 12V or 24V batteries.

The Samlex SB100 can handle a maximum continuous load of 40 amperes.

The SB100 can handle current spikes up to 300 amperes for 0.7 seconds.

Yes, the Samlex SB100 includes overvoltage protection that disconnects the load at 16 VDC.

The Samlex SB100 draws 3.2 mA, minimizing its impact on the battery.

Yes, the Samlex SB100 housing is made of rubberized polyurethane and is IP66 certified. This certification ensures protection against dust and powerful water jets, making it suitable for marine and mobile environments.

The SB100 offers 10 on/off voltage threshold programs. These programs are user-selectable via jumpers, allowing precise adaptation to the specific requirements of each installation.

Yes, the SB100 has a remote OFF command input. This allows the battery to be disconnected via an external switch.

Yes, the SB100 is equipped with an alarm/state indicator output. This output can signal an imminent low-voltage threshold or other system conditions.

The Samlex SB100 includes overcurrent and overheating protections. In the event of a critical issue, these protections automatically disconnect the loads.

The input and output voltage range of the Samlex SB100 is 6 to 35 VDC.

The Samlex SB100 is designed to protect onboard power systems and is compatible with 12V or 24V batteries. The specific battery type (starting, service, etc.) is not specified as a limitation, but it is intended for protection against excessive discharge.

The IP66 certification means that the SB100 housing is fully protected against dust and powerful water jets from all directions. This ensures its robustness in demanding environments.

The SB100 protects connected electronic devices by preventing excessive battery discharge and disconnecting them in case of overvoltage (cutoff at 16 VDC), ensuring their safety and longevity.

Yes, the Samlex SB100 is a smart and programmable disconnect device. It automatically disconnects the load when the battery voltage drops below a predefined threshold or in case of overvoltage, overcurrent, or overheating.

The Samlex SB100 integrates an automatic system voltage detection function, allowing it to adapt without manual intervention to either a 12V or 24V environment.

Using the SB100 prevents excessive battery discharge, protects electronic devices from voltage spikes, and ensures the longevity of the entire power system. It also offers configuration flexibility with its voltage threshold programs and built-in protections.

The SB100 offers 10 user-selectable start/stop voltage threshold programs via jumpers, allowing tailored configuration without being overly complex. 12V/24V voltage detection is automatic.

Yes, the SB100 is equipped with a remote OFF command input, allowing connection of an external switch to manually disconnect the battery if necessary.
