MPRX merekaabel sertifitseeritud 3G 6 mm²

Marine MPRX cable, 3G 6mm², rated 3G, for marine electrical distribution and onboard power connections. MPRX / CJPF, 3G6 mm². Sold by the meter.

Public priceGet pro pricing

6,83€

6,83€ ~~7,69€~~

6,83€ m

Käibemaksuga Tarne arvutatakse makse tegemise ajal.

Laosolekus

LONGUEUR :

M cm

1M 7,5M 10M 15M 20M 35M 50M

Longueur facturée : 1 m (arrondie au mètre supérieur)

Prix publicBénéficier du tarif pro

~~7,69€~~ TTC -11%

6,83€ TTC

soit 6,83€ / m (après remise)

Vous économisez : 0,86€

Free pickup point for orders over €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

via our network of certified installers

Find an installer

Support service

Choose additional installation support

Technical specifications

Kaabli tüüp	Power cable
Lõikeala (mm²)	6
Juhtmete arv	3
Paindlikkus	Flexible
Katte materjal	PVC
Juhtme materjal	Tinned copper
Juhtme viimistlus	Tin coated
Kaabli perekond	MPRX marine homologué
Kaabli segment	Câbles électriques / commande
Kaabli standard	MPRX / CJPF
Juhtimise konfiguratsioon	3G6 mm²
Juhtiv režiim	avec conducteur vert/jaune
Lõikepind (mm²)	6
Environment	Installation électrique bateau
Installation Check	section, nombre de conducteurs, couleur, longueur utile et mode de vente avant commande
Installation Context	Pose protégée en environnement nautique ou technique
Merekvaliteet	Oui
Standardiperekond	MPRX / CJPF
Väliskate	PVC
Product Usage	Distribution électrique marine et liaisons de puissance à bord
Skysat Positioning	câble électrique vendu en complément des installations énergie et distribution de bord
Müügühiku hoiatus	Unité de vente Odoo : mètre. Commander la longueur nécessaire en mètres.

Detailed description

MPRX merekaabel sertifitseeritud 3G 6 mm² on sertifitseeritud merekaabel, mis on mõeldud laevade elektrilise jaotuse ning jõujaotuse jaoks. See kuulub Skysati elektriliste komponentide valikusse, keskendudes jõu-, juhtimis- ja pardajaotuse kaablitele.

Tehniline perekond: MPRX / CJPF. Konfiguratsioon: 3G6 mm². Juhe: tinastatud vask. Väliskest: PVC. Valik tuleb kinnitada vastavalt läbilõikele, tegelikule pikkusele, elektrilisele kaitsele ja pardal asetusele.

See toode müüakse meetripikkuses. Enne tellimist mõõda tegelik pikkus, lisa vajalik teenindusmarginaal ja telli vajalikku pikkust vastav kogus.

Documentation

Type	Nom
	Catalogue marine - câbles MPRX homologués

Expert review

Pol CONIN

Digital Manager

« Review Skysat - MPRX marine cable certified 3G 6mm² »

Skysat advice: first size the cross-section based on current intensity, round-trip length, and allowable voltage drop, then select the cable family according to the installation environment.

For a clean installation, label both ends before threading, protect through-hull penetrations, avoid sharp bends, and leave service slack near terminals and protection devices.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

MPRX merekaabel sertifitseeritud 3G 6 mm²

6,83€

6,83€ ~~7,69€~~

6,83€ m

Frequently asked questions

Need help? Contact us

What is the purpose of MPRX marine cable 3G 6mm²?

MPRX marine cable 3G 6mm² is used for onboard electrical wiring, whether for power, control, or auxiliary connections, depending on its cross-section and MPRX marine homologation.

How to choose the correct wire size?

Wire size must be selected based on current intensity, round-trip length, acceptable voltage drop, and upstream protection.

What does the cable configuration mean?

The indicated configuration is 3G6 mm². The letter G usually indicates the presence of a green/yellow conductor, while X indicates a version without a protective conductor.

What needs to be checked before installation?

Check the actual path, bend radius, bulkhead penetrations, mechanical protection, and marking of both ends before crimping.

Can it be installed in a wet area?

Installation depends on the cable family and its sheath. In a wet or exposed environment, use a protected routing and properly insulated terminations.
