Raymarine

T910

Trostruki senzor Dubina/Brzina/Temperatura

Le Raymarine T910 est un émetteur de coque conçu pour traiter les données de profondeur, vitesse et température d'un triducer, s'intégrant au système 12/24Vdc du bateau. Cette unité est essentielle pour centraliser et transmettre ces informations de navigation. Inclus : vis auto-foreuses et gabarit de montage.

Public priceGet pro pricing

217,46€

217,46€ ~~252,00€~~

UK Isporuke izračunate u trenutku plaćanja.

Na zalihi

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat for onboard equipment installation

Request a quote

Installers near you

through our network of certified installers

Find an installer

Support service

Choose additional installation assistance

Technical specifications

Radni napon	12/24 V
Širina proizvoda	47 mm
Visina proizvoda	52.5 mm
Dubina proizvoda	42.5
Kompatibilnost sabirnice	NMEA 2000
Žičana mreža	NMEA 2000
Vrsta montaže	Montage en surface
Samozatvarajući ventil	Non
Ugrađeni	Non
Mjesto ugradnje	Intérieur, au-dessus de la ligne de flottaison, ventilé
Kalibracija brzine broda	Via système de navigation connecté
Mjerenje temperature	Oui
Vrsta izlaza senzora	Numérique (NMEA 2000)
Vrsta senzora	Interface de capteur multifonction

Detailed description

Raymarine T910 je odašiljač za ugradnju u oplatu namijenjen obradi podataka s trostrukog senzora (triducera) koji mjeri dubinu, brzinu i temperaturu. Ova jedinica služi kao sučelje između triducera i navigacijskog sustava broda, objedinjujući ove tri ključne vrijednosti za precizno praćenje. Kompatibilan je s brodskom naponom od 12/24Vdc te može biti napajan i solarnom pločom Raymarine u slučaju nedostatka namjenske energije.

Ugradnja i povezivost T910

Ugradnja Raymarine T910 zahtijeva strateško postavljanje na brodu. Jedinica se mora montirati okomito, s kabelima koji izlaze odozdo, i obvezno najmanje 50 cm iznad linije gaza. Izuzetno je važno izbjegavati izravan kontakt s vodom te odabrati dobro prozračenu zonu, isključujući hermetički zatvorene odjeljke. Montaža se izvodi pomoću tri rupe promjera 2,5 mm, koristeći priložene samonarezujuće vijke, s posebnom pažnjom da se ne previše zategnu kako ne bi došlo do oštećenja kućišta.

Detalji o kabliranju i integraciji

Spoj kabela tranducera na Raymarine T910 mora se izvesti prema specifičnom kodu boja. Za triducer, ekran mase mora biti spojen na konektor za dubinu, a ne na konektor za brzinu, kako bi se izbjegli kratki spojevi. Ako senzor brzine nema integriranu sondu za temperaturu, potrebno je povezati crveni i bijeli vodič konektora za brzinu kako bi se osigurala kontinuitet signala. Preporučuje se nanošenje silikonske masti na priključke za optimizaciju veze, kao i osiguranje kabela u blizini odašiljača. Konačno, poklopac mora biti pravilno postavljen kako bi se vanjske ovojnice kabela zadržale unutar odašiljača, osiguravajući adekvatnu zaštitu cjelokupnog kabliranja.

Documentation

Type	Nom
	EN - Gabarit de montage - Capteur Trifonctions Sondeur/Loch et Température
	EN - Notice d'installation - Capteur Trifonctions Sondeur/Loch et Température
	EN - Manuel d'utilisation - Capteur Trifonctions Sondeur/Loch et Température
	EN - Manuel d'utilisation - Capteur Trifonctions Sondeur/Loch et Température
	EN - Manuel d'utilisation - Capteur Trifonctions Sondeur/Loch et Température
	EN - Manuel d'utilisation - Capteur Trifonctions Sondeur/Loch et Température
	EN - Manuel d'utilisation - Capteur Trifonctions Sondeur/Loch et Température

Expert review

Pol Conin

Digitalni odgovorni

« Raymarine T910 interface: reliable triducer data management »

The Raymarine T910 is an essential hull-mounted transmitter for vessels requiring reliable centralization of core navigation data: depth, speed, and temperature. This module is not the sensor itself, but the electronic interface that receives and processes signals from an external triducer. Its functional value lies in converting raw sensor data into usable information for the onboard electronic system, often for integration into an NMEA or SeaTalkNG network; the NMEA output protocol is specifically mentioned in the technical documentation.

Installing the T910 requires consideration. As a hull-mounted transmitter, it is installed inside the vessel, simplifying maintenance and avoiding additional hull penetrations compared to a through-hull transducer. However, this involves specific constraints: vertical mounting, more than 50 cm above the waterline, and in a ventilated space away from direct moisture. These requirements are critical to ensure longevity and signal reliability. Installers must pay close attention to transducer wiring, including grounding the shield to the depth connector for triducers, and bridging the brown and white terminals if the speed sensor does not include a temperature probe. These details are decisive for proper operation and system integrity.

This type of interface is particularly relevant for owners looking to modernize or improve the reliability of their navigation data acquisition without replacing all their sensors. It serves as a key component for converting and transmitting basic data, often a prerequisite for display on multifunction instruments or dedicated screens. It is not suitable for direct exposure to the elements or installation in sealed compartments that would prevent necessary ventilation.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Trostruki senzor Dubina/Brzina/Temperatura

217,46€

217,46€ ~~252,00€~~

Frequently Asked Questions

Need help? Contact us

What are the prerequisites for drilling the mounting holes of the T910?

You must drill three 2.5 mm holes. These holes are marked "B" on the mounting template provided with the device.

Which screws should be used to mount the T910 and are there any precautions?

The T910 must be mounted using the self-tapping screws provided. It is critical not to overtighten the screws, as this could damage the housing molding.

How to connect the transducer cables to the T910?

Connecting the transducer cables to the Raymarine T910 must follow the specific color code indicated on the unit. It is also necessary to sleeve the shields to prevent short circuits.

How to connect the ground braid of a triducer to the T910?

For a triducer, the ground braid MUST be connected to the depth connector, not the speed connector. This prevents short circuits and ensures proper operation.

What to do if my speed sensor has no integrated temperature probe?

If your speed sensor does not include a temperature probe, you must connect the brown and white wires of the speed connector. This connection ensures signal continuity.

Should a product be applied to the T910 connection terminals?

Yes, it is recommended to apply silicone grease to the connection terminals to optimize connection quality and protect them.

How to ensure proper cable management after connection to the T910?

It is recommended to support the cables near the transmitter. Additionally, the unit's cover must be correctly positioned to keep the outer cable sheaths inside the transmitter, ensuring their secure attachment and protection.

How to check that the T910 cover is properly installed?

Ensure the cover is correctly fitted and locks the outer sleeves of the cables inside the transmitter housing. This ensures connection protection and installation durability.

Is the T910 compatible with all types of transducers?

The Raymarine T910 is specifically designed to be used with a triducer (triple-function transducer) measuring depth, speed, and temperature. Its compatibility will therefore depend on the type of triducer you have.

Can the T910 be used with older transducers?

Yes, the T910 can potentially be used with older transducers. However, it is advisable to carefully check the connections, especially if the speed sensor does not have an integrated temperature probe, in which case a link between the brown and white terminals of the speed connector will be required.

What types of data can the T910 process?

The T910 is designed to process and interface depth, speed (log), and temperature data. These three types of measurements are consolidated by the unit for your navigation system.

Can incorrect installation of the T910 affect the warranty?

Yes, failure to follow the installation instructions provided with the Raymarine T910 may void your warranty. It is therefore essential to strictly adhere to all guidelines for installation and wiring.
