Panell de gestió de bateria 16 interruptors unipolars

The BEP 800-MS3 panel is a centralized solution designed for continuous electrical distribution in marine systems. It integrates 16 single-pole circuit breakers to manage and protect up to 16 different onboard circuits.

This panel is designed to handle up to 16 independent circuits thanks to its 16 single-pole circuit breakers.

The BEP 800-MS3 panel uses Airpax magneto-hydraulic single-pole circuit breakers, known for their reliability and robustness in marine environments.

Airpax integrated circuit breakers feature a "trip-free" design. This prevents the circuit breaker from being forced into the ON position during an overload, ensuring continuous protection of the circuit.

The panel is made of marine-grade powder-coated aluminum, providing excellent resistance to corrosion and the demanding conditions of the marine environment.

Yes, the BEP 800-MS3 panel features backlit labels with green LEDs for optimal night visibility. Additionally, red LEDs indicate the "on" status of each system.

The maximum per bus or total amperage that the BEP 800-MS3 panel can handle is 160A, ensuring efficient power management for your equipment.

Typical circuit breaker configurations include a range of amp ratings such as 5A, 10A, 15A, 20A, and 25A, suitable for various equipment and electrical requirements.

The BEP 800-MS3 panel operates at a nominal voltage of 12V.

Yes, although its nominal voltage is 12V, the panel can be adapted to 24V systems by adding a resistor, typically for LED lighting circuits.

Thanks to its marine-grade powder-coated aluminum construction, the panel is designed to withstand demanding marine environments, including moisture and corrosion. However, it is recommended to install it in a location protected from direct water spray if possible.

Compared to fully digital solutions like those from CZone (also part of the Navico group), the BEP 800-MS3 offers a more traditional and mechanical approach to energy management, with physical circuit breakers for each circuit. This simplicity and robustness are appreciated by many users.

Yes, Airpax circuit breakers are designed to be replaceable. It is important to ensure any replacement circuit breaker has the same amp rating and specifications as the original to maintain system integrity.

The Contour design refers to the panel's aesthetics and shape, designed to blend seamlessly into a vessel's interior, providing a clean and modern finish while remaining functional.

For the main power panel, use appropriately gauged wiring capable of handling the total maximum amperage of 160A to ensure system safety and efficiency.

The BEP 800-MS3 panel is designed for continuous power distribution and centralized management of 16 circuits in marine systems. It allows you to control and protect various DC loads aboard your vessel using its integrated circuit breakers, providing a robust solution for power management.

The BEP 800-MS3 panel is designed to operate at a nominal voltage of 12V. However, it can be adapted for use with 24V systems by adding a resistor. It is recommended to consult a professional for this adaptation to ensure correct and safe installation.

The BEP 800-MS3 panel is equipped with Airpax single-pole magneto-hydraulic circuit breakers. These breakers are known for their reliability in marine environments and feature a "trip-free" design that prevents forced activation in case of overload, ensuring effective circuit protection.

Yes, absolutely. The BEP 800-MS3 panel is made of powder-coated marine-grade aluminum, providing excellent resistance to corrosion and harsh marine conditions. Its design also includes green LED backlit labels for night visibility and red LEDs to clearly indicate the "on" status of each system, ensuring durability and functionality.
