RC162

Distribuïdor de càrrega 1E/2S/160A

null

Public priceGet pro pricing

252,92€

252,92€ ~~263,40€~~

IVA inclòs Expedició calculada en el moment del pagament.

Estoc baix

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

through our network of certified installers

Find an installer

Service d'assistance

Choose additional assistance for installation

Technical specifications

Tensió nominal	12V/24V
Xarxa amb fil	Aucun
Corrent de càrrega màxim (A)	160.0
Nombre màxim de bateries en paral·lel	2.0
Orientació de muntatge	Verticale ou horizontale
Grau de protecció IP	Non spécifié
Pes	1.2
Battery Banks	2.0
Battery Isolation	Oui
Charge Distribution Method	Automatique (vers la batterie la moins chargée)
Combine Voltage	5-31 Vdc
Corrent continu (A)	160.0
Cooling Type	Passif
Número de model	ECS162 / FBECS1620000D00
Tipus de muntatge	Montage en surface
Pes net	1.2
Nombre d'entrades	1
Nombre de sortides	2
Open Voltage	5-31 Vdc
Dimensions del producte (L x A x F)	195 x 68 x 135
Tipus de relé	MOSFET
Start Isolation	Oui
Status Indicator	LED
Voltage Drop At Rated Current	Négligeable

Detailed description

Dissenyat per optimitzar la gestió energètica a bord, el distribuïdor de càrrega electrònic QUICK RC162 (model ECS162 / FBECS1620000D00) és una solució dedicada als sistemes de 12V i 24V. Aquest dispositiu permet recarregar de manera eficient i independent diversos parcs de bateries a partir d’una única font de càrrega, com un alternador. Amb una entrada i dues sortides, gestiona un corrent de càrrega màxim de 160 ampers per entrada, assegurant una distribució adequada a les bateries connectades.

Tecnologia MOSFET per a una càrrega optimitzada

El distribuïdor QUICK RC162 incorpora la tecnologia MOSFET, la qual li confereix l’avantatge principal de funcionar amb una caiguda de tensió negligible, fins i tot nul·la. A diferència dels distribuïdors de diodes tradicionals que poden provocar pèrdues de tensió significatives, aquest model garanteix que les bateries rebin la tensió completa de càrrega de l’alternador o carregador, optimitzant així la seva vida útil i la rapidesa de la seva recàrrega. Assegura l’aïllament dels parcs de bateries, impedint qualsevol descàrrega mútua, i distribueix automàticament el corrent cap a la bateria menys carregada per a una eficiència màxima.

Disseny i instal·lació

Amb unes dimensions de 195 x 68 x 135 mm (L x A x P) i un pes d’uns 1,2 kg, el RC162 presenta un disseny compacte que facilita la seva instal·lació i el seu cablejat en diversos entorns marins. El seu refredament passiu contribueix a la seva fiabilitat i al seu funcionament silenciós. Pot instal·lar-se en posició vertical o horitzontal, oferint flexibilitat d’integració. El distribuïdor és compatible amb un rang de tensió d’entrada de 5 a 31 Vdc i disposa d’un indicador LED de funcionament. Està dissenyat per a una baixa dissipació de potència i un ús sense manteniment en un ampli rang de temperatures ambientals. La documentació en PDF s’inclou per facilitar-ne la implementació.

Expert review

Pol CONIN

Responsable digital

« Analysis of the QUICK RC162 load distributor: MOSFET efficiency for multi-battery systems »

The QUICK RC162 electronic load distributor is a key component for modern marine electrical architectures. It is designed for vessels equipped with multiple battery banks (engine, service, bow thruster, etc.) requiring simultaneous and optimized charging from a single source, typically the main alternator. Its MOSFET technology represents a significant improvement over traditional diode-based distributors.

The main advantage lies in the near-total absence of voltage drop. While a diode-based distributor can induce a loss of 0.6 to 0.8 volts, reducing charging efficiency and battery lifespan, the RC162 ensures that battery banks receive the full alternator voltage. This is critical to guarantee complete charge cycles and preserve battery health in the long term. The 160A capacity is suitable for most standard onboard alternators.

From an installation standpoint, its compact size (195 x 68 x 135 mm (L x H x D)) and the ability to mount it vertically or horizontally offer valuable flexibility in often tight spaces. Integration with existing charging systems is simplified by its compact design and 12/24V compatibility. It is important to note that for very high-power alternators (over 160A), more robust battery management solutions or intelligent charging systems should be considered.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Distribuïdor de càrrega 1E/2S/160A

252,92€

252,92€ ~~263,40€~~

Complete your installation with

Complementary equipment

Caixa de relés per a guinche de 3 fils 12V 150A SUFFIX1001P

Quick

Caixa de relés per a guinche de 3 fils 12V 150A SUFFIX1001P

Ref : T6315-12

182,76€

182,76€ ~~208,08€~~

Lector de targetes / Lector LED Shark 10-30V Long. 30 cm

Quick

Lector de targetes / Lector LED Shark 10-30V Long. 30 cm

Ref : QL061

118,22€

118,22€ ~~124,80€~~

Frequently Asked Questions

Need help? Contact us

What is a battery distributor and what is it used for?

A battery combiner is a device designed to optimize energy management on board. It allows efficient and independent charging of multiple battery banks (e.g., engine battery and service batteries) from a single charging source, such as an alternator, while isolating these banks to prevent mutual discharge.

What technology is used in the QUICK RC162 load distributor?

The QUICK RC162 charge distributor integrates MOSFET technology. This technology gives it the major advantage of operating with negligible or even zero voltage drop.

What are the advantages of MOSFET technology for battery charging?

MOSFET technology offers several key advantages:

It minimizes voltage drop, ensuring batteries receive the full charging voltage from the alternator or charger. It optimizes battery lifespan and speeds up recharging. It ensures isolation between battery banks, preventing mutual discharge. It automatically distributes current to the least charged battery for maximum efficiency.

How many inputs and outputs does this load distributor have?

The QUICK RC162 charge distributor is equipped with one input (1E) and two outputs (2S). This means it can take power from a single source and distribute it to two separate battery banks.

What is the maximum charging current that the QUICK RC162 distributor can handle?

The QUICK RC162 charge distributor is designed to handle a maximum charging current of 160 amperes (160A) per input.

Does the RC162 splitter have an operating indicator?

Yes, the QUICK RC162 charge distributor is equipped with an LED indicator light to show its operating status.

Does the QUICK RC162 load distributor require active cooling?

No, the QUICK RC162 load distributor is designed with passive cooling. This contributes to its reliability and ensures silent operation.

What are the physical dimensions of the QUICK RC162 load distributor?

The dimensions of the QUICK RC162 load distributor are 195 mm in length, 68 mm in height, and 135 mm in depth (195 x 68 x 135 mm).

What is the approximate weight of the QUICK RC162 splitter?

The approximate weight of the QUICK RC162 load distributor is about 1.2 kg.

How does the QUICK RC162 splitter ensure isolation between battery banks?

The QUICK RC162 charge distributor uses MOSFET technology to effectively isolate the different battery banks connected. This isolation prevents any cross-discharge between batteries, ensuring that each bank maintains its charge independently of the others.

Does the distributor supply current equally to all batteries?

No, the QUICK RC162 splitter does not distribute current equally, but rather in an optimized manner. It automatically prioritizes sending current to the least charged battery, ensuring faster and more efficient charging of the entire system.

Is this splitter suitable for marine use?

Yes, the QUICK RC162 load distributor is designed for use in various marine environments, as indicated in its description. Its compact design makes it easy to integrate aboard boats.

What is the part number for this load distributor?

The model reference for this load distributor is RC162. It is also known by the designations ECS162 or FBECS1620000D00.

With which voltage systems is the QUICK RC162 splitter compatible?

The QUICK RC162 charge distributor is compatible with 12V and 24V electrical systems.

What is the acceptable input voltage range for this splitter?

The QUICK RC162 charge distributor is compatible with an input voltage range from 5 to 31 Vdc.

Can this splitter be used with different types of batteries?

The QUICK RC162 charge distributor is designed to efficiently and independently charge multiple battery banks in 12V and 24V systems. It is compatible with batteries commonly used in marine and vehicle applications, provided they meet the 12V or 24V operating voltage requirements.

Can the RC162 splitter be used with a shore power charger in addition to an alternator?

Yes, the QUICK RC162 load distributor is designed to charge multiple battery banks from a single charging source. This typically includes alternators, but also other sources such as shore power chargers, provided the input voltage range (5 to 31 Vdc) and maximum current (160A) are respected.

In which position can the QUICK RC162 load distributor be installed?

The QUICK RC162 charge distributor offers installation flexibility and can be mounted in either vertical or horizontal position, making it easier to integrate in various environments.

Is the wiring of the splitter complex?

The compact design of the QUICK RC162 splitter is intended to simplify installation and wiring. It is recommended to carefully follow the user manual instructions for correct and secure installation.

Is it necessary to allocate specific space for cooling during installation?

The QUICK RC162 splitter uses passive cooling. Although it does not require space for forced airflow, it is still recommended to install it in a location with good ambient air circulation to optimize its lifespan and performance.
