B75M BB TH perfilada 0°

The B75M transducer stands out with its mid-frequency CHIRP technology, offering an excellent compromise for versatile use in coastal and moderate offshore waters. Unlike low-frequency transducers (B75L) for deep waters or high-frequency transducers (B75H) for detailed shallow-water imaging, the B75M is designed for broader coverage. Its 0° profiling is specifically suited to hulls with low deadrise or where the hull angle is zero, ensuring optimized hydrodynamic performance.

CHIRP (Compressed High-Intensity Radiated Pulse) technology sends a frequency sweep across a wide band rather than a single fixed frequency. This results in better target separation, superior image clarity, and more precise detection of fish and underwater structures compared to traditional fishfinders.

The RAYMARINE B75M BB TH thru-hull transducer at 0° is designed to deliver accurate depth and water temperature data to compatible Raymarine navigation systems.

"Profilée 0 deg" means the transducer is designed to be installed on hulls with a deadrise angle (angle of the hull relative to horizontal) of 0 degrees, or in locations where the mounting surface is perfectly flat. This ensures the transducer is parallel to the water surface, maximizing signal quality and hydrodynamic performance.

The B75M transducer, with its CHIRP technology operating at mid-range frequencies, is an ideal compromise for versatile use. It is suitable for both coastal waters and moderate offshore waters, delivering good performance across a variety of depths.

A through-hull transducer (TH) such as the B75M BB TH offers several advantages. It is mounted directly through the hull, which significantly reduces turbulence around the sensor and maximizes signal quality. This is essential for obtaining reliable readings at high speeds and in rough seas, providing superior performance compared to transom-mount transducers.

No, this transducer is specifically designed to provide depth and temperature data only. It does not transmit speed data.

The RAYMARINE B75M BB TH 0° profiled sounder is a "black box" transducer designed to connect to Raymarine CHIRP-compatible fishfinder modules. It is compatible with modules such as the CP370, CP470, and CP570.

No, this is a black box type transducer. It is supplied with bare wires and must be connected to a compatible Raymarine CHIRP sounder module (such as the CP370, CP470, CP570), which will then connect to your multifunction display.

The RAYMARINE B75M BB TH 0° angled CHIRP transducer is specifically designed for the Raymarine ecosystem and its CHIRP sounder modules. Compatibility with equipment from other brands is not guaranteed and is generally not recommended.

No, the A80017 transducer is a CHIRP mid-frequency transducer. It requires a compatible Raymarine CHIRP sounder module to function properly. It is not compatible with traditional fixed-frequency sounder systems.

The RAYMARINE B75M BB TH profiled 0° transducer is a "black box" (BB) type transducer, meaning it is supplied with bare wires for direct and custom connection to a compatible RAYMARINE CHIRP fishfinder module. It does not come with a ready-to-use connector.

This transducer is specifically designed for through-hull (TH) installation on hulls with low deadrise or locations where the hull angle is 0 degrees. It is ideal for boats with a relatively flat mounting surface.

Yes, as this is a through-hull transducer (TH), installation requires drilling a hole in the boat's hull to insert the transducer body. This ensures direct contact with the water and optimal performance.

Installing a through-hull transducer like the B75M BB TH requires drilling the hull and ensuring perfect watertightness. While an experienced sailor may be able to do it, it is strongly recommended to hire a qualified professional to guarantee a correct and secure installation, avoiding any risk of water infiltration.

The term "0-degree profiling" means the transducer itself is designed for a 0-degree angle. During installation, it is critical to select a hull location where the deadrise angle is closest to 0 degrees, or use a fairing block to compensate for the hull angle and ensure the transducer face is perfectly parallel to the water surface.

The exact diameter of the hole to drill depends on the precise model and the installation specifications provided by Raymarine. It is imperative to consult the official installation manual for product A80017 to obtain this critical information and avoid any errors.

Yes, the location is crucial. The depth sounder must be installed in an area of the hull where water flow is most laminar and free of air bubbles, away from propellers, keels, water intakes, or any other disturbances. A good location minimizes turbulence and maximizes signal quality for accurate readings.

For installation, you will typically need a drill with an appropriate hole saw (diameter to be checked in the manual), marine sealants (mastic), sandpaper, surface cleaner, and potentially clamping tools. The specific tools and exact materials are detailed in the installation guide provided by Raymarine.

Watertight integrity is ensured by using specific marine sealants and gaskets provided or recommended by the manufacturer. During installation, the transducer body is inserted into the drilled hole, and sealing products are generously applied between the transducer and the hull, as well as around the fastenings, to prevent any water infiltration. It is essential to strictly follow the installation manual instructions.
