Raymarine

T905

Sonda sondador transversal o adhesiva 50 mm

Conçu pour intégrer les données de vos sondes de profondeur, vitesse et température, l'émetteur de coque Raymarine T905 (SKU T905) assure une connexion fiable au système de bord. Compatible avec une alimentation 12/24Vdc, il est destiné à une installation verticale dans un environnement ventilé, à l'abri de l'eau. Le kit inclut les vis auto-foreuses nécessaires à la fixation.

Public priceGet pro pricing

148,27€

148,27€ ~~162,00€~~

IVA inclòs Expedició calculada en el moment del pagament.

En estoc

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

through our network of certified installers

Find an installer

Service d'assistance

Choose additional assistance for installation

Technical specifications

Tecnologies de sondatge compatibles	Sondeur analogique (profondeur, vitesse, température)
Tensió de funcionament	12/24 Vdc
Tipus de connector per a sondes	Fils nus / Bornier à vis
Amplada del producte	52.5 mm
Alçada del producte	90 mm
Fondària del producte	42.5 mm
Grau de protecció IP	Non applicable (doit être monté au-dessus de la ligne de flottaison)
Compatibilitat de bus	Analogique
Connectivitat sense fils	Non
Tipus de muntatge	Montage mural / Vertical
Sensor de velocitat integrat	Non
Sensor de temperatura integrat	Non

Detailed description

Dissenyat per a sistemes de navegació marina, l’emissor de buc Raymarine T905 gestiona la transmissió de les dades provinents de les sondes de profunditat, velocitat i temperatura. Aquest mòdul és essencial per centralitzar la informació dels transductors cablejats cap als instruments de bord, oferint una solució d’integració per a diverses configuracions de sensors.

Instal·lació i connectivitat del T905

La instal·lació de l’emissor T905 requereix un muntatge vertical a un mínim de 50 cm per sobre de la línia de flotació, en un espai ben ventilat i sense contacte directe amb l’aigua. No s’ha de muntar en un compartiment estanc. S’alimenta mitjançant una font de 12/24Vcc i també pot ser alimentat per un panell solar Raymarine. La connexió dels cables dels transductors es realitza segons un codi de colors precís, amb instruccions específiques per als Triducers (la massa s’ha de connectar al connector de profunditat) i per als sensors de velocitat sense sensor de temperatura (enllaç entre els terminals marró i blanc).

Integració de les dades de sondes

El T905 permet consolidar els senyals de sondes diferents (profunditat, velocitat, temperatura) en un únic punt. Requerix l’aplicació de greix de silicona als contactes per garantir la fiabilitat de les connexions. La tapa del contenidor assegura el manteniment i la protecció de les fundes exteriors dels cables. Aquest tipus d’emissor s’utilitza sovint en sistemes on es prioritza la flexibilitat d’integració de les sondes existents respecte a l’ús de transductors «tot-en-un» o de sistemes NMEA 2000 directes, com es podria veure en productes més recents de la gamma Axiom de Raymarine o d’altres marques com Garmin o B&G.

Documentation

Type	Nom
	EN - Gabarit de montage - Sonde sondeur traversante ou à coller 50mm
	EN - Notice d'installation - Sonde sondeur traversante ou à coller 50mm
	EN - Manuel d'utilisation - Sonde sondeur traversante ou à coller 50mm
	EN - Manuel d'utilisation - Sonde sondeur traversante ou à coller 50mm
	EN - Manuel d'utilisation - Sonde sondeur traversante ou à coller 50mm
	EN - Manuel d'utilisation - Sonde sondeur traversante ou à coller 50mm
	EN - Manuel d'utilisation - Sonde sondeur traversante ou à coller 50mm

Expert review

Pol CONIN

Responsable digital

« Wired transducer integration via Raymarine T905 hull-mounted transducer »

The Raymarine T905 hull transmitter is a critical component for integrating existing or specific wired transducers into a boat’s instrumentation network. Its practical value lies in its ability to bridge classic depth, speed, and temperature transducers with the display system, often within a wireless architecture (such as Raymarine’s Tacktick/Micronet systems). This is particularly relevant for sailboats where minimizing wiring and installation flexibility are key advantages.

For optimal installation, it is essential to follow mounting guidelines: vertically, at least 50 cm above the waterline, in a ventilated environment, and protected from direct water contact. This is not a submersible device nor intended for sealed compartments. Standard 12/24Vdc power is required, with the option to use a Raymarine solar panel for isolated installations.

The T905 stands out due to its function as a converter and transmitter for wired transducers, offering an alternative to directly NMEA 2000-compatible or wireless transducers. It is ideal for those who wish to retain high-performance existing transducers or face cable routing constraints. It is critical to observe specific wiring requirements for Triducers and speed transducers without temperature sensors to ensure correct operation. This module is not a transducer itself but the core that interprets and transmits signals from your sensors.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Sonda sondador transversal o adhesiva 50 mm

148,27€

148,27€ ~~162,00€~~

Complete your installation with

Complementary equipment

Raymarine

Display i50 Depth sondador

Ref : E70059

514,55€

514,55€ ~~594,00€~~

Raymarine

Display i50 Speed

Ref : E70058

552,56€

552,56€ ~~594,00€~~

Raymarine

Mostrador digital i50 Tridata

Ref : E70060

567,25€

567,25€ ~~654,00€~~

Raymarine

Display multifunció i70s

Ref : E70327

678,00€

678,00€ ~~714,00€~~

Frequently Asked Questions

Need help? Contact us

What are the mounting requirements for the T905 transducer?

For correct installation, the T905 must be mounted vertically in a well-ventilated area at least 50 cm above the waterline. Direct contact with water must be avoided.

At what height above the waterline should the T905 be mounted?

The T905 transducer must be mounted at least 50 cm above the waterline to ensure proper operation and prevent direct contact with water.

Can the T905 be installed in a watertight compartment?

No, the T905 must NOT be installed in a watertight compartment. It must be mounted in a well-ventilated area.

In which orientation should the T905 transducer be mounted?

The T905 must be mounted vertically, with the cables exiting from the bottom of the unit. It is important to note that the mounting template must be inverted relative to the transducer itself.

How to mount the T905 on the boat?

To mount the T905, drill three 2.5 mm holes at the positions marked "B" on the mounting template. The transmitter is then secured using the provided self-tapping screws. Do not overtighten the screws to avoid damaging the housing.

What is the procedure for connecting the transducer cables to the T905?

Connect the transducer cables to the T905 by following the color-coding indicated on the unit. It is essential to sleeve the cable shields to prevent short circuits. Once connected, apply silicone grease to the contacts.

Is there a specific guideline for wiring a Triducer with the T905?

Yes, for a Triducer, the ground braid (the shielding) must be connected to the depth connector and NOT to the speed connector.

How to connect a speed sensor without a temperature sensor to the T905?

If your speed sensor does not include an integrated temperature sensor, you must connect the brown and white wires of the speed connector with a jumper to ensure proper data transmission.

Should silicone grease be applied to the T905 contacts?

Yes, it is recommended to apply silicone grease to the terminal contacts after connecting the transducer cables. This helps ensure the reliability of the connections.

How to protect cables after connection to the T905?

After connecting the cables, it is important to support them near the transmitter. Then ensure the housing cover is properly fitted, as it is designed to hold and protect the outer cable sleeves inside the transmitter.

With which types of systems is the T905 designed to operate?

The T905 is designed to operate with marine navigation systems requiring centralized data from wired transducers (depth, speed, temperature) to onboard instrumentation. It provides a solution to integrate existing sensors.

Is the T905 an alternative to direct NMEA 2000 systems?

Yes, the T905 is often used in setups where flexible integration of existing transducers is preferred over "all-in-one" sensors or direct NMEA 2000 systems. It provides a different method for sensor data integration.
