Commutador de bomba de sentina

The RULE A Matic 35A (reference RL035) switch is a critical device for automatic bilge pump management. It detects water levels and activates or deactivates the pump accordingly, enhancing navigation safety.

This switch is specifically designed for marine electrical systems operating at 12V and 24V.

The RULE A Matic RL035 switch can switch a maximum current of 14 amperes at 12V and 7 amperes at 24V.

No, this switch integrates a mercury-free float switch, ensuring environmental compliance while providing reliable water level detection.

The RULE 35A switch is equipped with 16 AWG wiring (approximately 1.29 mm²) with a length of 712 mm.

No, the RL035 model (35A) does not include a protective plate. This feature is available on other models in the RULE range, such as the 40A.

Its primary function is to automate the operation of bilge pumps by detecting the water level. It activates the pump when the water level is too high and deactivates it once the water is pumped out, helping to keep the bilge dry without manual intervention.

The RULE 35A switch is a standard model suitable for medium-capacity bilge pumps, handling up to 14A at 12V and 7A at 24V. For pumps requiring higher current handling, other RULE models such as the 37A or 40A are available, which can manage up to 20A at 12V.

The installation of the switch must be carried out in accordance with ABYC (American Boat and Yacht Council) standards for marine electrical systems, as well as ISO 10133:2000.

The switch must be installed at the same level or above the pump base to ensure positive and effective pump shut-off, thus preventing residual water accumulation.

Yes, it is essential to disconnect the electrical power source from the system before performing any installation, repair, or maintenance on the unit. This precaution is critical to prevent bodily injury, damage to the environment, and/or damage to the unit itself.

Yes, it is always necessary to install a properly sized fuse. This prevents damage to the product in case of a short circuit. The absence of an adequate fuse could result in pump malfunction, injury, and/or fire risk.

The float switch can be used with most bilge pumps compatible with 12V or 24V voltages and whose maximum current does not exceed 14A at 12V or 7A at 24V. It is crucial to check the amperage of your pump to ensure optimal compatibility and avoid any damage.

Yes, this device is designed to operate specifically with fresh water and salt water. Using it with other liquids is strongly discouraged.

The switch is compatible with 12V and 24V direct current (DC) electrical systems, commonly used in marine applications.

The RL035 model complies with the following standards:

EN 61000-6-1:2001EN 61000-6-3:2007ISO 10133:2000 (regarding very low voltage electrical systems for recreational craft)

No, this switch is designed for use only with fresh water and salt water. Using it with other hazardous, corrosive, or flammable materials may result in pump damage, environmental harm, exposure to hazardous substances, and bodily injury.

The RULE A Matic 35A switch (part number RL035) is covered by a 2-year warranty.

The RULE 35A float switch is positioned as a standard model for medium-capacity bilge pumps. It is complemented by higher-capacity models such as the 37A and 40A, which can handle up to 20A at 12V, providing options for different amperage requirements.

The RL035 model (35A) comes with a 2-year warranty. In comparison, the 37A model has a longer 5-year warranty, while the 40A model, like the 35A, also has a 2-year warranty.
