BEP Marine

779-LB-2-B

Medium busbar 35.5 to 42.5 mm 650 A for 8 to 10 mm fuse holder

The BEP 779-LB-2-B medium busbar, part of the Pro Installer range, is designed for high-current electrical connections in marine environments. With a 650A capacity, it connects fuse holders with diameters of 8 to 10mm, maintaining a spacing of 35.5 to 42.5mm. The product includes the busbar only.

Retail priceBenefit from the professional rate

6,50€

6,50€ ~~7,38€~~

Tax included. Shipping calculated at checkout.

Available in stock

Free pickup point from €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

thanks to our network of approved installers

Find an installer

Support service

Opt for additional installation assistance

Technical specifications

Product type	Linking bar
ABYC compliance	Oui
Abyc Compliant	Yes
Amperage	650.0
Product barcode	779-LB-2-B
Bep Product Series	Pro Installer
Busbar application type	Mariner
Busbar base material	Fiberglass-reinforced polymer
Busbar Base Material Reinforcement Type	Fiber
Busbar Base Material Resistance	High temperatures
Busbar Conductor Grade	CDA102
Busbar conductor material	Tinned copper
Busbar Conductor Shape	Mount
Busbar Material	Tinned copper, fiber-reinforced polymer
Busbar type	Bridge
Cable Entry Flexibility	Yes
Certifications	CE
Color	Metal
Compatible Fuse Mounting Stud Diameter Mm	8 to 10
Fastener material	Stainless steel
Conductor Material Alloy	CDA102
Conductor Material Plating	Tinned
Corrosion resistance	Yes
Cover included	Oui
Cover material	Polycarbonate
Cover Protection Sides	3
Cover Removable Sides	Yes
Cover transparency	Transparent
Durability	Yes, in marine environment
Electrical connection method	Stud mount
Fastener Corrosion Prevention	Stainless steel construction to prevent seizing
Fastener type	Bolts, washers, nuts
Flame retardant	Oui
Suitability for high-power applications	Yes
Humidity Operating Range Percent	0-95% non-condensing
Interconnection Height Common Feature	Yes, for easier integration with other BEP Pro Installer products
Intrastat Code Description	Parts suitable for use solely or principally with the apparatus of heading 8535, 8536 or 8537, n.e.s. (excl. electronic assemblies, and boards, panels, consoles, desks, cabinets and other bases for the goods of heading 8537, not equipped with their apparatus, and for wafer probers of subheading 8536.90.20)
IP rating	IP00
Link Bar Center To Center Distance Mm	35.5-42.5
Link bar design type	Medium
Link bar overall length	42.5
Manufacturer	BEP
Maximum cable lug size	M10
Maximum DC voltage	50
Modular Design	Yes
Mounting type	Screw-in
Nominal voltage	50 V
Number Of Link Bars Per Kit	1
Nut Material	Stainless steel
Odoo Category Full Path	Merchandise / NAVICO GROUP / 11 - BEP / CZone (35)
Operating Temperature Range C	-40°F to +176°F
Product Purpose Electrical	Power distribution
Product range	Pro Installer
Product Variant Count	1
Public Category Ids	7
Product SKU	779-LB-2-B
Storage Temperature Range C	-40°F to +176°F
Number of studs	2.0
Stud Material	Stainless steel
Stud size (mm)	8 mm, 10 mm
Supported System Voltages	12V, 24V, 48V
System Integration Benefit	Common interconnection height
Number of terminals	2.0
Terminal thread size (mm)	M8, M10
Serial number tracking	none
Uom Name	u
Volume Cm3	0
Washer Material	Stainless steel
Washer Type Included	Washers
Weight Unit	kg

Detailed description

Designed to optimize electrical connections in demanding marine installations, the BEP 779-LB-2-B medium busbar is a key component of the Pro Installer system. This device enables the creation of robust and organized connections between fuse holders or other compatible electrical elements.

Integration and performance

The BEP 779-LB-2-B busbar is specifically sized to connect components with a spacing of 35.5 to 42.5 mm, accepting studs with a diameter of 8 to 10 mm. It can handle a continuous current of 650A at a maximum voltage of 50V DC, making it suitable for 12V, 24V, and 48V systems. This capacity positions it as a solution for high-power circuits, offering a structured alternative to conventional jumper cables.

Robust and modular design

Manufactured with tinned copper conductors (CDA102), known for their conductivity and corrosion resistance, and base materials in high-temperature-resistant fiberglass, this busbar ensures durability in marine environments. The studs, washers, and nuts in stainless steel prevent seizing and improve the longevity of the installation. Its design aligns with the modularity of the BEP Pro Installer system, ensuring a common interconnection height for easy integration with other BEP products. The transparent protective covers, equipped with removable side skirts, provide three-sided insulation and flexibility for cable entry.

Expert opinion

Pol CONIN

Digital Manager

« BEP Pro Installer busbar: robustness and power circuit integration »

The medium BEP 779-LB-2-B busbar is an essential component for structuring and securing high-power marine electrical installations. Its primary function is to consolidate connections between heavy-duty fuse holders or other distribution elements, typically in main circuits or for demanding consumers.

In an installation scenario, it is often used to connect two fuse holders or a fuse holder to a main busbar, ensuring stable current distribution and minimizing losses. The advantage of this busbar lies in its integration with the BEP Pro Installer system, enabling compact and professional arrangement in electrical panels or engine compartments.

This product differs from simple jumper cables by its ability to maintain precise and standardized spacing between components, which is crucial for consistency and compatibility within the BEP Pro Installer system. The materials used, such as tinned copper, along with its 650A capacity, make it suitable for critical applications where reliability and high-current management are paramount.

It is important to note that this busbar is specifically designed for spacings of 35.5 to 42.5mm and studs of 8 to 10mm. Therefore, it is essential to verify compatibility with existing fuse holders or terminal blocks. It is not intended for low-ampacity connections, where its cost and size would be oversized for the application. Its maximum benefit lies in the organized and secure management of high currents.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Medium busbar 35.5 to 42.5 mm 650 A for 8 to 10 mm fuse holder

6,50€

6,50€ ~~7,38€~~

Frequently Asked Questions

Need help? Contact us

What is the BEP 779-LB-2-B link bar?

The BEP 779-LB-2-B busbar is an electrical component designed to optimize connections in marine installations. It enables the creation of robust and organized links between fuse holders or other compatible electrical elements, forming an integral part of BEP's Pro Installer system.

What materials are used to manufacture this tie rod?

This link bar is made with tinned copper conductors CDA102, known for their conductivity and corrosion resistance. The base is in fiber-reinforced material, resistant to high temperatures, and the studs, washers, and nuts are in stainless steel to prevent seizing and improve longevity.

What is the maximum current rating of this busbar?

The BEP 779-LB-2-B tie bar can handle a continuous current of 650 amperes (650A).

What is the maximum voltage supported by this tie bar?

It is designed to operate at a maximum voltage of 50V DC.

Is the connecting bar supplied with protection for the connections?

Yes, it is fitted with transparent protective covers. These covers have removable side skirts, providing three-sided insulation and flexibility for cable entry.

Is this product part of a modular system?

Yes, its design is part of the BEP Pro Installer system’s modularity, ensuring a common interconnection height for easier integration with other BEP products in the same range.

Is the tie bar corrosion-resistant in a marine environment?

Yes, it is designed for durability in marine environments. Tinned copper conductors (CDA102) and stainless steel studs, washers, and nuts contribute to its high corrosion resistance.

What is the primary function of this tie bar?

The primary function of this interconnect bar is to provide a structured and robust solution for interconnecting electrical components, such as fuse holders, in high-power circuits, offering an organized alternative to conventional jumper cables.

Which types of studs or terminals can be connected to this busbar?

This tie bar is specifically designed to accept pins with a diameter of 8 to 10 mm.

Is it compatible with 12 V, 24 V or 48 V electrical systems?

Yes, it is compatible with 12V, 24V, and 48V systems, as it can handle a continuous current of 650A at a maximum voltage of 50V DC, making it suitable for these common voltages.

Which other BEP products is this tie bar compatible with?

It is designed to integrate with the BEP Pro Installer system, ensuring a common interconnection height with other products in this range. It is specifically sized to connect fuse holders or other compatible electrical components.

What is the terminal spacing range this busbar can connect?

This interconnect bar is specifically sized to connect components with a spacing of 35.5 to 42.5 mm.

Can this tie bar be used as an alternative to conventional tie cables?

Yes, it provides a structured and robust solution for high-power circuits, serving as an alternative to conventional interconnecting cables while improving connection organization and reliability.

How do the linkage bar protective covers facilitate cable entry?

The transparent protective covers feature removable side skirts. This design allows flexibility for cable entry from different angles while ensuring effective sealing on three sides.

Are there specific spacing requirements for components during installation?

Yes, the link bar is designed to connect components with a precise spacing of 35.5 to 42.5 mm. It is essential to ensure that the components to be connected comply with this spacing range for correct and secure installation.

Is the BEP 779-LB-2-B tie bar easy to integrate into an existing installation?

Yes, thanks to its modular design and common interconnection height with other BEP Pro Installer products, it is designed for easy and orderly integration into existing electrical panels or systems.

Is it necessary to take special precautions when handling studs and nuts?

The studs, washers, and nuts are made of stainless steel to prevent seizing. It is recommended to use appropriate tools and to tighten to the torque specified by the manufacturer to ensure a secure and durable electrical connection without damaging the components.

How to ensure proper insulation of connections with this bus bar?

The tie bar comes with transparent protective covers that provide insulation on three sides. It is crucial to ensure these covers are properly installed and closed after making all connections to guarantee optimal insulation and the safety of the installation.

Can the tiller extension be cut or modified to fit a different spacing?

No, the link bar is designed for a specific spacing of 35.5 to 42.5 mm and must not be cut or modified. Any alteration could compromise its structural integrity, current capacity, safety, and void any compliance.

Is the tiller bar suitable for installations where temperatures may be high?

Yes, the base of the tie bar is made of fiber-reinforced material, a material known for its resistance to high temperatures, making it suitable for environments where heat can be a factor.
