Raymarine

R70385

Gasket for flush mount AXIOM Pro 9 / eS9

The Raymarine R70385 gasket is a spare part designed for flush-mounting Raymarine AXIOM Pro 9 and eS9 multifunction displays. This gasket provides essential water and moisture sealing to protect your MFD's electronics in marine environments. It is compatible with these specific Raymarine models, ensuring reliable installation compliant with original equipment standards.

Retail priceBenefit from the professional rate

48,97€

48,97€ ~~54,00€~~

Tax included. Shipping calculated at checkout.

In stock

Free pickup point shipping over €150 in France
Pickup at Skysat possible

Custom installation

Trust Skysat to install the equipment on board

Request a quote

Installers near you

thanks to our network of approved installers

Find an installer

Support service

Opt for additional installation assistance

Technical specifications

Mounting type	Flush-mounted
Material	Marine-grade polymer
Color	Black
Compatible models	Raymarine AXIOM Pro 9, Raymarine eS9
IP rating	IPX6, IPX7
Finish	Fairlead
Installation type	Flush-mounted
Kit contents	1x Sealing gasket
Product type	Seal gasket

Detailed description

Designed to ensure the integrity of your multifunction display installation, the Raymarine R70385 flush mount gasket is an essential spare part. It provides optimal sealing when integrating your chartplotter into the dashboard or console. This gasket is specifically sized for the Raymarine AXIOM Pro 9 and eS9 models, protecting the internal electronics from water and moisture ingress in a marine environment.

Reliable integration and protection

Using an original Raymarine gasket, such as the R70385, is critical to maintaining the performance and durability of the AXIOM Pro 9 and eS9 displays. While the Axiom range has expanded with models like the Axiom+, Axiom 2 Pro, and Axiom XL, this gasket remains dedicated to the specific AXIOM Pro 9 and eS9 generations, ensuring perfect compatibility and a compromise-free installation. It is a key component for preserving the IP rating of your MFD, essential in exposed marine environments.

Raymarine-specific compatibility

This gasket aligns with Raymarine’s policy of providing spare parts tailored to its equipment. It is intended for users of AXIOM Pro 9 and eS9 chartplotters looking to replace a worn or damaged gasket, or during a new flush installation. Compatibility is strictly defined for these two multifunction display models, ensuring precise fitment and sealing function compliant with original specifications.

Documentation

Type	Nom
	FR - Manuel d'utilisation - Joint pour montage encastré AXIOM Pro 9 / eS9

Expert opinion

Pol CONIN

Digital Manager

« Importance of the sealing gasket for Raymarine AXIOM Pro 9 and eS9 MFDs »

The Raymarine R70385 recessed mounting gasket is an often overlooked component, but it is critical for the longevity and reliability of AXIOM Pro 9 and eS9 multifunction displays. In a marine environment, the watertight integrity of a recessed-mounted device is the first line of defense against water, salt, and moisture infiltration, which can lead to costly failures. This gasket ensures that the screen’s original ingress protection rating (IP) is maintained after installation, protecting internal electronic components. Using an OEM gasket is mandatory as it is designed with precise tolerances and materials resistant to UV and marine conditions, unlike generic solutions that may degrade quickly or fail to provide adequate sealing. During installation or replacement, it is essential to ensure the gasket is correctly positioned and free of deformation to guarantee uniform compression and perfect sealing. A poorly installed or damaged gasket directly compromises your MFD’s protection and may void the warranty in case of water infiltration.

Durabilité

Facilité d'installation

Rapport performance / prix

Payment and security

Your payment information and data are processed securely.

Gasket for flush mount AXIOM Pro 9 / eS9

48,97€

48,97€ ~~54,00€~~

Frequently Asked Questions

Need help? Contact us

What is the Raymarine R70385 recessed mounting gasket used for?

The Raymarine R70385 recessed mounting gasket is an essential spare part designed to ensure the integrity of your multifunction display installation. It provides optimal sealing when integrating your chartplotter into the dashboard or console, protecting the internal electronics from water and moisture ingress in a marine environment.

Which Raymarine display models is this gasket compatible with?

This gasket is specifically sized and compatible with Raymarine AXIOM Pro 9 and eS9 multifunction display models. It is designed for precise fitment and sealing performance to original specifications for these two models.

Can I use this gasket with newer Axiom models such as the Axiom+ or the Axiom 2 Pro?

No, this gasket is strictly dedicated to the specific Raymarine AXIOM Pro 9 and eS9 generations. It is not compatible with newer Axiom models such as the Axiom+, Axiom 2 Pro, or Axiom XL, as it ensures perfect compatibility and hassle-free installation only with the designated models.

Why is it important to use this gasket when installing in a flush mount?

Using this gasket is essential to maintain the performance and longevity of your AXIOM Pro 9 and eS9 displays. It ensures optimal sealing, protecting the internal electronics from water and moisture ingress, and is a key component for preserving the ingress protection (IP) rating of your MFD, which is critical in exposed marine environments.

Is this an original Raymarine part?

Yes, the R70385 is an original Raymarine seal. Using an original seal is recommended to ensure perfect compatibility and watertightness compliant with the manufacturer's specifications.

When should this seal be replaced or installed?

This seal is intended for users of AXIOM Pro 9 and eS9 chartplotters who need to replace a worn or damaged seal. It is also required during a new flush-mounted installation of these multifunction displays to ensure proper sealing from the start.

How does this gasket protect the electronics of my MFD?

When flush-mounting your AXIOM Pro 9 or eS9 display, this gasket creates a watertight seal between the unit and the dashboard or console. This barrier prevents water, moisture, and spray from seeping in and reaching the internal electronics of your MFD, thereby preserving its functionality and lifespan in a marine environment.

What is the primary function of the R70385 seal?

The primary function of the R70385 seal is to ensure optimal watertight integrity for Raymarine AXIOM Pro 9 and eS9 multifunction displays when installed flush-mounted. It ensures the device's electronics are protected from marine elements.
