Raymarine Ray 90/91 primary station pack wireless included wireless handset, wireless access point and active speaker

The Raymarine T70433 pack is an expansion solution that includes the following:

A wireless handsetA dedicated wireless hubAn active speakerThis pack is designed to extend the communication capabilities of the Raymarine Ray90 and Ray91 modular VHF systems.

The primary function of the T70433 pack is to extend onboard communication capabilities for Raymarine Ray90 and Ray91 modular VHF systems. It enables converting a wired VHF installation into a hybrid system, providing increased flexibility for voice and DSC communications from multiple points on the vessel without requiring long cables for the handset.

The wireless handset included in the T70433 pack is powered via a dedicated charging cradle. This cradle ensures the handset remains charged and provides freedom of movement on deck or in other areas of the vessel.

The wireless hub acts as a critical gateway. It provides wireless connectivity between the wireless handset and the Ray90 or Ray91 VHF base station, enabling the handset to function as a fully operational remote communication station.

Yes, the T70433 pack is supplied with an active speaker. It is designed to provide superior audio clarity, which is essential in noisy marine environments, allowing VHF communications to be heard distinctly.

The wireless handset provides controls similar to a Raymic wired handset, including:

Power button to turn on/off and access shortcuts.PTT (Push to Talk) button for voice transmission.Integrated microphone.Channel Up/Down buttons to change VHF channels and adjust menu options.LCD screen.Back button to navigate menus.OK/Menu button to access menu/DSC functions and confirm selections.16/+ button to toggle between priority channels.HI/LO button to switch between High (25 W) and Low (1 W) transmission power.Distress button under a spring-loaded cover for DSC distress calls.Volume Up/Down and VOL/SQ buttons to adjust volume and squelch.Integrated speaker.

The T70433 pack is an extension solution. It is specifically designed to complement and extend the functionality of existing Raymarine Ray90 and Ray91 modular VHF radios by adding a complete wireless station. It is not a standalone VHF system.

The exact dimensions of the wireless handset and its charging cradle are not detailed in the provided technical documentation excerpts for this product.

When installing the wireless hub, it is critical to pay close attention to antenna orientation to ensure optimal performance. A site survey should also be conducted to determine the best location, taking into account wireless product placement requirements to maximize coverage and minimize interference.

Yes, to avoid RF interference and ensure optimal performance, it is recommended to follow installation guidelines for multiple antennas. These include separating antennas and maintaining safe distances from the compass. A site survey before installation is advised to identify the best locations.

Yes, it is strongly recommended to perform a site survey (Pre-installation site survey) before installing the wireless components of the T70433 package. This survey determines the optimal locations for the access point and the handheld unit's charger to ensure maximum wireless performance and minimize interference risks.

Yes, the active speaker is designed to provide superior audio clarity, essential in noisy marine environments. It is recommended to install it in accordance with the manufacturer's guidelines to maximize this clarity and clearly hear VHF communications.

It is imperative to ensure that the vessel's electrical power supply is turned off before starting installation of this product. Never connect or disconnect the equipment while power is active unless explicitly stated otherwise in the documentation. Components require power connections compliant with the manufacturer's specifications, including distribution diagrams and appropriate fuse recommendations.

The Ray 90/91 Raymarine T70433 wireless primary station pack is specifically designed to be compatible with Raymarine Ray90 and Ray91 modular VHF systems. It integrates with these radios to extend their communication capabilities.

The T70433 pack is an extension for Ray90/91 VHF radios. Compatibility with Raymarine multifunction displays (MFD) is handled by the Ray90/91 base station itself. Details on specific MFD models compatible with Ray90/91 radios are not included in the documentation excerpts provided for this pack.

Yes, the Ray90 and Ray91 base stations are modular and can support multiple handsets. In addition to the wireless handset supplied with the T70433 pack, it is possible to connect up to two wired handsets (Raymic) to the handset station connectors on a Ray90 or Ray91.

The T70433 pack is specifically designed for Ray90 and Ray91 systems. While some wireless components (such as generic wireless handsets or speakers) may be referenced in Ray63/73 documentation for troubleshooting, the T70433 pack as an extension is dedicated to Ray90/91 models.

Yes, Raymarine recommends installation by a Raymarine-certified installer. A certified installation may provide enhanced product warranty benefits. For details, consult a Raymarine dealer or the product warranty document provided with the purchase.
